Preface
MicroLogix 1000 Programmable Controllers User Manual
9–16
Masked Move (MVM)
The MVM instruction is a word instruction that moves data from a source location
to a destination, and allows portions of the destination data to be masked by a
separate word. As long as the rung remains true, the instruction moves the data each
scan.
Entering Parameters
Enter the following parameters when programming this instruction:
Source
is the address of the data you want to move.
Mask
is the address of the mask through which the instruction moves data; the
mask can be a hex value (constant).
Destination
is the address where the instruction moves the data.
Updates to Arithmetic Status Bits
With this Bit: The Controller:
S:0/0 Carry (C) always resets.
S:0/1 Overflow (V) always resets.
S:0/2 Zero (Z) sets if result is zero; otherwise resets.
S:0/3 Sign (S) sets if result is negative; otherwise resets.
Execution Times
(µsec) when:
True False
33.28 6.78
MVM
MASKED MOVE
Source
Mask
Dest
