Controller Specifications
Controller Types
Catalog Number Description
1761-L16AWA 10 pt. ac input, 6 pt. relay output, ac power supply controller
1761-L32AWA 20 pt. ac input, 12 pt. relay output, ac power supply controller
1761-L20AWA-5A
12 pt. ac input, 4 pt. analog input, 8 pt . r elay output, 1 pt. analog output, ac
powe
r s uppl y c ontroller
1761-L10BWA 6 pt. dc input, 4 pt. relay output, ac power supply controller
1761-L16BWA 10 pt. dc input, 6 pt. relay output, ac power supply controller
1761-L20BWA-5A
12 pt. dc input, 4 pt. analog input, 8 pt . r elay output, 1 pt. analog output, ac
powe
r s upply controller
1761-L32BWA 20 pt. dc input, 12 pt. relay output, ac power supply controller
1761-L10BWB 6 pt. dc input, 4 pt. relay output, dc power supply controller
1761-L16BWB 10 pt. dc input, 6 pt. relay output, dc power supply controller
1761-L20BWB-5A
12 pt. dc input, 4 pt. analog input, 8 pt . r elay output, 1 pt. analog output, dc
powe
r s upply controller
1761-L32BWB 20 pt. dc input, 12 pt. relay output, dc power supply controller
1761-L16BBB 10 pt. dc input, 4 pt. FET and 2 pt . r elay outputs, dc powe r s upply controller
1761-L32BBB 20 pt. dc input, 10 pt. FET and 2 pt . r elay outputs, dc powe r s upply controller
1761-L32AAA 20 pt. ac input, 10 pt . t riac and 2 pt . r elay outputs, ac powe r s upply controller
efesotomasyon.com - Allen Bradley,Rockwell,plc,servo,drive

Allen-Bradley MicroLogix 1000 Specifications

General

Communication Ports	RS-232
Power Supply	24V DC or 120/240V AC
Programming Software	RSLogix 500
Manufacturer	Allen-Bradley
Category	Controller
Series	MicroLogix
Programming Language	Ladder Logic
Input Voltage	24V DC or 120/240V AC
I/O Points	10 to 32 points
Processor Type	8-bit
Operating Temperature	0…55 °C (32…131 °F)
Processor	8-bit
