Using the Message Instruction
13–11
Error
Code
Description of Error Condition
02H Target node is busy.
03H Target node cannot respond because message is too large.
04H
Target node cannot respond because it does not understand the command parameters OR
the control block may have been inadvertently modified.
05H Local processor is offline (possible duplicate node situation).
06H Target node cannot respond because requested function is not available.
07H Target node does not respond.
08H Target node cannot respond.
09H Local modem connection has been lost.
0AH Buffer unavailable to receive SRD reply.
0BH Target node does not accept this type of MSG instruction.
0CH Received a master link reset.
10H
Target node cannot respond because of incorrect command parameters or unsupported
command.
15H Local channel configuration parameter error exists.
18H Broadcast (Node Address 255) is not supported.
1AH
➀
Target node cannot respond because another node is file owner (has sole file access).
1BH
➀
Target node cannot respond because another node is program owner (has sole access to
all files).
37H Message timed out in local processor.
39H Message was discarded due to a communication protocol switch.
3AH Reply from target is invalid.
50H Target node is out of memory.
60H Target node cannot respond because file is protected.
E7H Target node cannot respond because length requested is too large.
EBH Target node cannot respond because target node denies access.
ECH Target node cannot respond because requested function is currently unavailable.
FAH Target node cannot respond because another node is file owner (has sole file access).
FBH
Target node cannot respond because another node is program owner (has sole access to
all files).
➀
Error codes 1A and 1B valid for Series C discrete only.
Note For 1770–6.5.16 DF1 Pr otocol and Command Set users:
The MSG err or code r eflects the STS field of the reply to your MSG instruction.
Codes E0 – EF represent EXT STS codes
0 – F . Codes F0 – FC r epresent EXT STS codes 10 – 1C.
Programming
