Recommended Surge Suppressors
We recommend the Allen-Bradley sur ge suppressors shown in the following table
for use with Allen-Bradley relays, contactors, and starters.
Device Coil Voltage
Suppressor Catalog
Number
Bulletin 509 Motor Starter
Bulletin 509 Motor Starter
120V ac
240V ac
599-K04
599-KA04
Bulletin 100 Contactor
Bulletin 100 Contactor
120V ac
240V ac
199-FSMA1
199-FSMA2
Bulletin 709 Motor Starter 120V ac 1401-N10
Bulletin 700 Type R, RM Relays ac coil None Required
Bulletin 700 Type R Relay
Bulletin 700 Type RM Relay
12V dc
12V dc
700-N22
700-N28
Bulletin 700 Type R Relay
Bulletin 700 Type RM Relay
24V dc
24V dc
700-N10
700-N13
Bulletin 700 Type R Relay
Bulletin 700 Type RM Relay
48V dc
48V dc
700-N16
700-N17
Bulletin 700 Type R Relay
Bulletin 700 Type RM Relay
115-125V dc
115-125V dc
700-N11
700-N14
Bulletin 700 Type R Relay
Bulletin 700 Type RM Relay
230-250V dc
230-250V dc
700-N12
700-N15
Bulletin 700 Type N, P, or PK Relay 150V max, ac or DC 700-N24
Miscellaneous electromagnetic devices
limited to 35 sealed VA
150V max, ac or DC 700-N24
