Allen-Bradley MicroLogix 1000 User Manual

Preface
MicroLogix 1000 Programmable Controllers User Manual
B–22
Mnemonic Instruction TypeName
Memory Usage
(user words)
True Execution
Time (approx.
µseconds)
False Execution
Time (approx.
µseconds)
HSD 7.00 8.00 1.25
High-Speed
Counter Interrupt
Disable
High-Speed
Counter
HSE 7.00 10.00 1.25
High-Speed
Counter Interrupt.
Enable
High-Speed
Counter
HSL 7.00 66.00 1.50
High-Speed
Counter Load
High-Speed
Counter
IIM 6.78 35.72 1.50
Immediate Input
with Mask
Program Flow
Control
INT 0.99 1.45 0.50
Interrupt
Subroutine
Application
Specific
IOM 6.78 41.59 1.50
Immediate Output
with Mask
Program Flow
Control
JMP 6.78 9.04 1.00 Jump to Label
Program Flow
Control
JSR 4.25 22.24 1.00
Jump to
Subroutine
Program Flow
Control
LBL 0.99 1.45 0.50 Label
Program Flow
Control
LEQ 6.60 23.60 1.50
Less Than or
Equal
Comparison
LES 6.60 23.60 1.50 Less Than Comparison
LIM 7.69 36.93 1.50 Limit Test Comparison
LFL 33.67 61.13 1.50 LIFO Load Data Handling
LFU 35.08 64.20 1.50 LIFO Unload Data Handling
MCR 4.07 3.98 0.50
Master Control
Reset
Program Flow
Control
MEQ 7.69 28.39 1.50
Masked
Comparison for
Equal
Comparison
MOV 6.78 25.05 1.50 Move Data Handling
efesotomasyon.com - Allen Bradley,Rockwell,plc,servo,drive

Allen-Bradley MicroLogix 1000 Specifications

General

Communication Ports	RS-232
Power Supply	24V DC or 120/240V AC
Programming Software	RSLogix 500
Manufacturer	Allen-Bradley
Category	Controller
Series	MicroLogix
Programming Language	Ladder Logic
Input Voltage	24V DC or 120/240V AC
I/O Points	10 to 32 points
Processor Type	8-bit
Operating Temperature	0…55 °C (32…131 °F)
Processor	8-bit
