MicroLogix 1000 Programmable Controllers User Manual
C–4
Instruction Description Instruction
Parameters
Valid Addressing
Mode(s)
Valid File Types Valid Value
Ranges
ADD Add source A immediate, direct,
indexed direct
O, I, S, B, T, C, R, N –32,768–32,767
f-min–f-max
source B immediate, direct,
indexed direct
O, I, S, B, T, C, R, N –32,768–32,767
f-min–f-max
destination direct, indexed direct O, I, S, B, T, C, R, N Not Applicable
AND Logical AND source A immediate, direct,
indexed direct
O, I, S, B, T, C, R, N –32,768–32,767
source B immediate, direct,
indexed direct
O, I, S, B, T, C, R, N –32,768–32,767
destination direct, indexed direct O, I, S, B, T, C, R, N Not Applicable
BSL Bit Shift Left file indexed direct O, I, S, B, N Not Applicable
control direct R (element level) Not Applicable
bit address direct O, I, S, B, T, C, R, N
(bit level)
Not Applicable
length (contained in the
control register)
0–2048
BSR Bit Shift Right file indexed direct O, I, S, B, N Not Applicable
control direct R (element level) Not Applicable
bit address direct O, I, S, B, T, C, R, N
(bit level)
Not Applicable
length (contained in the
control register)
0–2048
CLR Clear destination direct, indexed direct O, I, S, B, T, C, R, N Not Applicable
COP Copy File source indexed direct O, I, S, B, T, C, R, N Not Applicable
destination indexed direct O, I, S, B, T, C, R, N Not Applicable
length immediate 1–128; 1–42
when destination
is T,C,R
