Allen-Bradley MicroLogix 1000

Preface
MicroLogix 1000 Programmable Controllers User Manual
D–14
Catalog
Number
Description
Installation
Requirement
Function Publication
1747-L511,
-L514,
-L524,
-L531, -L532
-L541,
-L542, -L543
-L551, -L552
-L553
SLC 500
Processors
SLC Chassis
These processors support a
variety of I/O requirements and
functionality.
1747-6.2
1746-BAS
BASIC Module SLC Chassis
Provides an interface for
SLC 500 devices to foreign
devices. Program in BASIC to
interface the 3 channels (2
RS232 and 1 DH-485) to
printers, modems, or the
DH-485 network for data
collection.
1746-6.1
1746-6.2
1746-6.3
1785-KA5
DH+/DH-485
Gateway
(1771) PLC
Chassis
Provides communication
between stations on the
PLC-5 (DH + ) and SLC 500
(DH-485) networks. Enables
communication and data
transfer from PLC  to SLC 500
on DH-485 network. Also
enables programming software
programming or data
acquisition across DH+ to
DH-485.
1785-6.5.5
1785-1.21
2760-RB
Flexible Interface
Module
(1771) PLC
Chassis
Provides an interface for
SLC 500 (using protocol
cartridge 2760-SFC3) to other
A-B PLCs and devices. Three
configurable channels are
available to interface with Bar
Code, V ision, RF , Dataliner ,
and PLC systems.
2760-ND001
1784-KTX,
-KTXD
PC DH-485 IM
IBM XT/AT
Computer Bus
Provides DH-485 using RSLinx 1784-6.5.22
1784-PCMK PCMCIA IM
PCMCIA slot in
computer and
Interchange
Provides DH-485 using RSLinx
1784-6.5.19
