Preface
MicroLogix 1000 Programmable Controllers User Manual
4–16
Design
Functional Specification
Perform
Detailed Analysis
Determine if Special
Programming
Features are Needed
Confirm I/O
Addresses
Enter/Edit
Program
Check for
Completeness
Monitor/Troubleshoot
Program
Accept
Program
❏ Prepare a general description of how you want your
automated process to operate.
❏ Identify the hardware requirements.
❏ Match inputs and outputs with actions of the process.
❏ Add these actions to the functional specifications.
Do you need:
❏ Special interrupt routines?
❏ High-speed counting features?
❏ Sequencing Operations?
❏ FIFO or LIFO stack operations?
❏ Make sure I/O addresses match correct input and
output devices.
❏ Enter program using the programming device.
❏ Review your functional specification and detailed
analysis for missing or incomplete information.
❏ Monitor and, if necessary , troubleshoot the
program that you entered.
❏ Resulting programs should match functional
specifications.
Run program.
Program Development
Process
Program Development
Checklist
Create Logic
Program
❏ Use worksheets if necessary to create program.
efesotomasyon.com - Allen Bradley,Rockwell,plc,servo,drive

Allen-Bradley MicroLogix 1000 Specifications

General

Communication Ports	RS-232
Power Supply	24V DC or 120/240V AC
Programming Software	RSLogix 500
Manufacturer	Allen-Bradley
Category	Controller
Series	MicroLogix
Programming Language	Ladder Logic
Input Voltage	24V DC or 120/240V AC
I/O Points	10 to 32 points
Processor Type	8-bit
Operating Temperature	0…55 °C (32…131 °F)
Processor	8-bit
