Rockwell Automation Publication 2711R-UM001E-EN-E - January 2017 19
Configuration Mode Chapter 2
PanelView Explorer Startup Window
PanelView Explorer Startup Window
Item Function Description
1 Terminal Settings Use this link to view and change terminal display and communication settings, view
system information, and enable terminal security while connected to the terminal.
2 File Transfer Transfers files between the storage media of the terminal and your computer, such as
screen saver bitmaps and applications. You can also delete applications from terminal
storage and export the alarm history log.
3 Sign off Logs you off the Startup window, leaving your browser open.
4 Terminal Type and Status Shows the connection status to your terminal and the type of terminal.
5 Languages Shows the current and available languages for PanelView Explorer.
6 Test, Run Use these buttons to test and run the selected application.
7 Available Applications Shows a list of applications stored on the terminal, USB flash drive, or micro-SD card.
The list also shows if the file has been validated for correct operation.
8 Stop Click the Stop button (the stop sign shown when an app is loaded and in Test/Run mode)
to unload the currently loaded application. If you have not saved changes to the
application, you are prompted to do so. Once the application is unloaded, the terminal
displays the Configuration screen.
