96 Rockwell Automation Publication 2711R-UM001E-EN-E - January 2017
Chapter 7 Recipes
4. You can optionally assign a Status Tag to monitor the status of the recipe
downloads and uploads.
You can now add ingredients to the recipe.
Add Ingredients to a Recipe
A recipe can hold up to 50 ingredients. Each ingredient is created as a separate
row in the recipe table. When you create a recipe, a row is automatically added for
the first ingredient. Each recipe must have at least one ingredient.
Follow these steps to add ingredients to a recipe.
1. Select a recipe in the Recipe List.
2. Click the Add Ingredient button for each ingredient you want to add to
the recipe.
3. For each ingredient:
a. change the name of the ingredient if required.
b. select the tag to store the value of the ingredient.
From firmware revision 4.011 onwards, recipe names and
recipe filenames are restricted to only English characters
(alphanumeric and certain special characters). If you use
non-English characters, you will not be able to save the recipe.
This does not affect the usability of the recipe, it can still be
downloaded to the terminal.
This limitation is due to the new feature that allows you to edit
the recipe name in the terminal, which supports only English
characters on the terminal keyboard.
If non-English characters are used, the field is outlined in red
and the OK button is grayed out.
