14 PanelView Plus and PanelView Plus Compact 400 and 600 Terminals
Publication 2711P-IN002G-EN-P - November 2009
600 Terminal Dimensions
266
(10.47)
167
(6.58)
185
(7.28)
152
(6.0)
68
(2.68)
98
(3.86)
98
(3.86)
68 (2.68)
154 (6.08)
600 Keypad or
Keypad and Touch
600 Touch
154 (6.08)
71 (2.81)
71 (2.81)

Table of Contents

Other manuals for Allen-Bradley PanelView Plus 600

Preview: Technical Data
Technical Data36 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Allen-Bradley PanelView Plus 600 and is the answer not in the manual?

Allen-Bradley PanelView Plus 600 Specifications

General IconGeneral
Resolution320 x 240 pixels
TouchscreenAnalog resistive
BacklightLED
Operating SystemWindows CE
Power Supply24V DC
Communication PortsEthernet, RS-232
Memory64 MB RAM
Operating Temperature0°C to 50°C
Enclosure RatingNEMA 4X
ProcessorXScale processor
