Allen-Bradley PanelView Plus 600 Installation Instructions

26 PanelView Plus and PanelView Plus Compact 400 and 600 Terminals
Publication 2711P-IN002G-EN-P - November 2009
Specifications
PanelView Plus and PanelView Plus Compact 400 and 600 Terminals
Attribute Value
Display
400 and 600 grayscale display
400 and 600 color display
Grayscale passive matrix, film compensated super-twist nematic
(FSTN) LCD technology
Color active matrix, thin film transistor (TFT) LCD technology
Display size, Approx., diagonal
400 grayscale display
400 color display
600 grayscale/color display
95 mm (3.7 in.)
89 mm (3.5 in.)
139 mm (5.5 in.)
Display area (WxH), Approx.
400 grayscale display
400 color display
600 grayscale/color display
77 x 58 mm (3.0 x 2.3 in.)
71 x 53 mm (2.8 x 2.1 in.)
112 x 84 mm (4.4 x 3.3 in.)
Display resolution
400 grayscale/color display
600 grayscale/color display
320 x 240
320 x 240
Backlight
400 grayscale/color display
600 grayscale/color display
LED
CCFL 50,000 hours life, min.
Touch Screen
Touch screen Analog resistive
Actuating rating 1 million presses
Operating force 10…110 g
Keypad
Function keys 8 or 10 function, numeric and navigation keys
Actuation rating 1 million presses
Operating force 340 g
Electrical
Input voltage, DC
Power consumption, DC
24V DC nom (18…30V DC)
25 W max (1.0 A @ 24V DC)
Input voltage, AC
Power consumption, AC
85…264V AC, 47…63 Hz
60V A max

Allen-Bradley PanelView Plus 600 Specifications

General

Resolution	320 x 240 pixels
Touchscreen	Analog resistive
Backlight	LED
Operating System	Windows CE
Power Supply	24V DC
Communication Ports	Ethernet, RS-232
Memory	64 MB RAM
Operating Temperature	0°C to 50°C
Enclosure Rating	NEMA 4X
Processor	XScale processor
