Allen-Bradley Ethernet Driver
Data Types Description
Data Type Description
Boolean Single bit
Byte Unsigned 8-bit value
Char Signed 8-bit value
Word Unsigned 16-bit value
Short Signed 16-bit value
DWord Unsigned 32-bit value
Long Signed 32-bit value
BCD Two-byte packed BCD, four decimal digits
LBCD Four-byte packed BCD, eight decimal digits
Float 32-bit IEEE floating-point
String Null-terminated character array
Note: The DWord, Long, and LBCD data types are not native to any of the PLC models. When referencing a
16-bit location as a 32-bit value, the location referenced is the low word and the next successive location is the
high word. For example, if N7:10 is selected as a DWord data type, N7:10 is the low word and N7:11 the high
word.
www. kepware.com
18

Allen-Bradley PLC-5 series Specifications

General

Network Type	Ethernet, ControlNet, DeviceNet, DH+
Protocols Supported	Ethernet/IP, ControlNet, DeviceNet, DH+
Product Line	PLC-5
ControlNet	Yes
DeviceNet	Yes
DH+	Yes
Communication Protocol	EtherNet/IP, ControlNet, DeviceNet, DH+
Compatible Processors	PLC-5 processors
Operating Temperature	0°C to 60°C
Relative Humidity	5% to 95% non-condensing
