Allen-Bradley PowerFlex 20-750-DCBB2-F6 Programming Manual

162 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 3 Drive Port 0 Parameters
DIAGNOSTICS
Fault/Alarm Info
953 Fault Status B
Fault Status B
RO 32-bit
Integer
Indicates the occurrence of conditions that have been configured as faults.
Bit 0 “Aux InputFlt” –
Bit 1 “OverVoltage” – Over voltage trip occurred.
Bit 2 “Drive OL” – Indicates the drive is overloaded. P940 [Drive OL Count] reached 100%.
Bit 3 “Heatsink OT” – Indicates the drive heatsink is over temperature. P943 [Drive Temp Pct] reached 100%.
Bit 4 “TransistorOT” – Indicates the transistor (IGBT) junction is over temperature. P941 [IGBT Temp Pct] reached 100%.
Bit 5 “SinkUnderTmp” – Indicates the heatsink temperature is under -18.7 °C (-2 °F).
Bit 6 “Excess Load” – Motor did not come up to speed in the allotted time during autotune.
Bit 7 “Overspd Lmt” – When set, indicates that a F25 “OverSpeed Limit” fault has occurred. This is a non-configurable fault. An overspeed condition results when
the motor speed falls outside of its normal operating range. The limits of this range are established by P521 [Max Rev Speed] - P524 [Overspeed Limit] = (lower
limit) and P520 [Max Fwd Speed] + P524 [Overspeed Limit] = (upper limit). In flux vector control mode or scaler control mode with encoder, the motor speed used
is a 2msec averaged value of P131 [Active Vel Fdbk]. In scaler control mode without an encoder, the overspeed check uses P1 [Output Frequency]. The overspeed
condition must exist for at least 16 milliseconds before it causes a fault to occur.
Bit 8 “Prchrg Open” – Precharge relay is open.
Bit 9 “SafetyBrdFlt” – Safety board is in a faulted state.
Bit 10 “IRVoltsRange” – The Autotune IR voltage exceeded the range of P73 [IR Voltage Drop].
Bit 11 “FluxAmpsRang” – The Autotune Flux Current exceeded the range of P75 [Flux Current Ref].
Bit 12 “IXOVoltRange” – The Autotune Ixo voltage exceeded the range of P74 [Ixo Voltage Drop].
Bit 13 “AuRstExhaust” – The value set in P348 [Auto Rstrt Tries] has been exceeded.
Bit 14 “SW OverCur” – Drive output current has exceeded the 1ms 250% current rating.
Bit 15 “HW OverCur” – Drive output current has exceeded the hardware current trip limit.
Bit 16 “TrqPrvSpdBnd” – The allowable deviation between actual motor speed and ramped speed set in P1105 [Speed Dev Band] has been exceeded.
Bit 17 “TPEnclsCfg” – The Torque Proving function has been configured as Encoderless. Read the Attention statement under Lifting/Torque Proving on page 356
.
Bit 18 “Ground Fault” – Current path to earth ground greater than 25% drive rated current detected.
Bit 19 “OW Alarm TO” – An A65 “OW TrqLvl Timeout” alarm has occurred.
Bit 20 “Over Travel” – The selected digital input for one of the over travel directions is active.
Bit 21 “TrvlLimCflct” – Travel limits are in conflict.
Bit 22 “End Lmt Sw” – The selected digital input for one of the end limit switches, P196 [DI Fwd End Limit] or P198 [DI Rev End Limit], has detected a falling edge
and P313 [Actv SpTqPs Mode] is not set to 1 “Speed Reg.”
954 Status1 at Fault
Status 1 at Fault
RO 32-bit
Integer
Captures and displays P935 [Drive Status 1] bit pattern at the time of the last fault.
See parameter 935 [Drive Status 1] for bit descriptions.
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved End Lmt Sw Tr vlLimCf lc t Over Travel OW Alarm TO Ground Fault TPEnclsCfg
(1)
TrqPrvSpdBnd
(1)
(1) 755 drives only.
HW OverCur SW OverCur AuRstExhaust IXOVoltRange FluxAmpsRang IRVoltsRange SafetyBrdFlt Prchrg Open Overspd Lmt Excess Load SinkUnderTmp TransistorOT Heatsink OT Drive OL OverVoltage Aux InputFlt
Default00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = Condition False
1 = Condition True
Options
Regen Motor OL Enable On Bus Frq Reg Cur Limit At Limit At Home AtZero Speed Torque Mode PositionMode Speed Mode DB Active DC Braking Stopping Jogging Running Reserved SpdRef Bit 4 SpdRef Bit 3 SpdRef Bit 2 SpdRef Bit 1 SpdRef Bit 0 Manual At Speed Faulted Alarm Decelerating Accelerating Actual Dir Command Dir Active Ready
Default00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109876543210
0 = Condition False
1 = Condition True
