Allen-Bradley PowerFlex 20-750-DCBB2-F6 Programming Manual

170 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 3 Drive Port 0 Parameters
DIAGNOSTICS
Peak Detection
1044 Peak2 Cfg
Peak 2 Configure
RW 16-bit
Integer
Configures operation of each peak detector.
Bit 0 “Peak2 Peak” – 0 = Capture minimum value of the input signal. 1 = Capture maximum value of the input signal.
Bit 1 “Peak2 Hold” – 0 = Monitor input. 1 = Ignore input and hold output at present value. This bit is overridden by Bit 2.
Bit 2 “Peak2 Set” – 0 = Resume normal capture of the input signal value (assuming Bit 1 is also = 0). The preset signal will be used as a starting value to compare
against further changes in the input signal level. 1 = Force output of the peak detect function to equal the signal selected by [PkDtctnPresetSel].
1045 Peak 2 Change
Peak 2 Change
RO 16-bit
Integer
Status of the peak detectors.
1046 PeakDetect2 Out
Peak Detection 2 Output
Displays the output of the peak detector, according to the operation selected by the
configuration bits, and is always displayed as a real number, regardless of the selected
signal type.
Default:
Min/Max:
0.000000
–/+2147483648.000000
RO Real
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
755
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Peak2 Set Peak2 Hold Peak2 Peak
Default0000000000000000
Bit 1514131211109876543210
755
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Peak2Change
Default0000000000000000
Bit 1514131211109876543210
0 = Output value is held or set.
1 = Output value has changed.
755
