Allen-Bradley PowerFlex 20-750-DCBB2-F6 Programming Manual

206 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 3 Drive Port 0 Parameters
APPLICATIONS
Spindle Orient
1581 SO Status
Spindle Orientation Status
RO 16-bit
Integer
Indicates status of spindle orientation logic.
Bit 0 “At SO Speed” – Drive running at Spindle Orientation velocity.
Bit 1 “Mode” – Drive in Spindle Orientation mode.
Bit 2 “Orient Cplt” – In selected Spindle Orientation position.
1582 SO Setpoint
Spindle Orientation Setpoint
Sets the desired Spindle Orientation Position in user-defined units.
Can use the value of P1590 [SO Unit Out] if an offset other than zero is required.
Default:
Min/Max:
0.00
0.00 / 536870912.00
RW Real
1583 SO Offset
Spindle Orientation Offset
Sets the offset encoder counts for the Home position. This value is loaded automatically
when the Homing function is run (typically after power up).
Default:
Min/Max:
0
–/+536870912
RW 32-bit
Integer
1584 SO EPR Input
Spindle Orientation Edges Per Revolution Input
Indicates the edges per revolution of the encoder. For example a 1024 quad encoder
equals 4096 (4 x 1024).
Default:
Min/Max:
4096
1 / 67108864
RW 32-bit
Integer
1585 SO Rvls Input
Spindle Orientation Revolutions Input
Sets the revolutions of the input gear relative to the output gear (14
:1).
Default:
Min/Max:
1.00
–/+1000000.00
RW Real
1586 SO Rvls Output
Spindle Orientation Revolutions Output
Sets the revolutions of the output gear relative to the input gear (14:1
).
Default:
Min/Max:
1.00
1.00 / 2000000.00
RW Real
1587 SO Cnts per Rvls
Spindle Orientation Counts Per Revolution
Sets the counts per revolution of the output gear.
Typically P1584 [SO EPR Input] x Gear Ratio.
Default:
Min/Max:
4096
1024 / 536870912
RW 32-bit
Integer
1588 SO Unit Scale
Spindle Orientation Unit Scale
Scales P1589 [SO Position Out] to user-defined units.
Typically set to Desired Units/P1587 [SO Cnts per Rvls].
Default:
Min/Max:
1.00000
–/+220000000.00000
RW Real
1589 SO Position Out
Spindle Orientation Position Output
Displays the present position of the output gear in encoder counts.
Default:
Min/Max:
0
0 / 4294967295
RO 32-bit
Integer
1590 SO Unit Out
Spindle Orientation Unit Output
Displays the present position of the output gear in user-scaled units.
Default:
Min/Max:
0.00
–/+220000000.00
RO Real
1591 SO Accel Time
Spindle Orientation Acceleration Time
Sets the acceleration rate used during positioning.
Units:
Default:
Min/Max:
Secs
10.00
0.00 / 3600.00
RW Real
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
755
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Orient Cplt Mode At SO Speed
Default0000000000000000
Bit 1514131211109876543210
0 = Disabled
1 = Enabled
755
755
755
755
755
755
755
755
755
755
