Rockwell Automation Publication 750-PM001N-EN-P - February 2017 221
Port 10 and Port 11 Parameters Chapter 4
File
Group
No. Display Name
Full Name
Description
Values
Read-Write
Data Type
CONVERTER N
Metering
115
215
315
C1 L1 Phase Curr
C2 L1 Phase Curr
C3 L1 Phase Curr
Converter n Line 1 Phase Current
Input current present at terminal L1 (R phase) of converter n.
Units:
Default:
Min/Max:
Amps
0.0
–/+9000.0
RO Real
116
216
316
C1 L2 Phase Curr
C2 L2 Phase Curr
C3 L2 Phase Curr
Converter n Line 2 Phase Current
Input current present at terminal L2 (S phase) of converter n.
Units:
Default:
Min/Max:
Amps
0.0
–/+9000.0
RO Real
117
217
317
C1 L3 Phase Curr
C2 L3 Phase Curr
C3 L3 Phase Curr
Converter n Line 3 Phase Current
Input current present at terminal L3 (T phase) of converter n.
Units:
Default:
Min/Max:
Amps
0.0
–/+9000.0
RO Real
118
218
318
C1 Gnd Current
C2 Gnd Current
C3 Gnd Current
Converter n Ground Current
The RMS ground current of AC input to converter n. The value displayed is based on the
sum of converter n drive input currents (L1, L2, and L3). When the three phases are
balanced, the ground current is ideally close to zero.
Units:
Default:
Min/Max:
Amps
0.0
–/+9000.0
RO Real
119
219
319
C1 DC Bus Volt
C2 DC Bus Volt
C3 DC Bus Volt
Converter n DC Bus Voltage
DC bus voltage measured by converter n.
Units:
Default:
Min/Max:
V DC
0.0
0.0 / 1200.0
RO Real
120
220
320
C1 Heatsink Temp
C2 Heatsink Temp
C3 Heatsink Temp
Converter n Heatsink Temperature
Temperature of the converter n heatsink.
Units:
Default:
Min/Max:
DegC
0.0
–/+200.0
RO Real
121
221
321
C1 SCR Temp
C2 SCR Temp
C3 SCR Temp
Converter n SCR Frequency
Maximum temperature of all SCRs for converter n.
Units:
Default:
Min/Max:
DegC
0.0
–/+200.0
RO Real
122
222
322
C1 GateBoardTemp
C2 GateBoardTemp
C3 GateBoardTemp
Converter n Gate Board Temperature
Gate board temperature for converter n.
Units:
Default:
Min/Max:
DegC
0.0
–/+200.0
RO Real
123
223
323
C1 AC Line Freq
C2 AC Line Freq
C3 AC Line Freq
Converter n AC Line Frequency
AC line frequency of converter n.
Units:
Default:
Min/Max:
Hz
0.0
0.0 / 100.0
RO Real
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
