Rockwell Automation Publication 750-PM001N-EN-P - February 2017 235
Embedded Feature and Option Module Parameters Chapter 5
Embedded EtherNet/IP
81
82
83
84
Fr Peer Addr 1
Fr Peer Addr 2
Fr Peer Addr 3
Fr Peer Addr 4
From Peer Address 1…4
Sets the bytes in the IP address that specifies the device from which the adapter receives
(consumes) Peer I/O data.
Important: The Peer Inp Addr must be on the same subnet as the embedded EtherNet/
IP adapter.
Changes to these parameters are ignored when P85 [Fr Peer Enable] is “1” (On).
For detailed information on peer communications, refer to the PowerFlex 755 Drive
Embedded EtherNet/IP Adapter User Manual, publication 750COM-UM001.
Default:
Min/Max:
0
0 / 255
RW 32-bit
Integer
85 Fr Peer Enable
From Peer Enable
Controls whether Peer I/O input is operating. A value of 0 “Off” turns off Peer I/O input. A
value of 1 “Cmd/Ref” overrides the settings in Parameters P76 [DLs Fr Peer Cfg], P78
[Logic Src Cfg], and P79 [Ref Src Cfg] and automatically uses peer Datalink 01 as the
drive's present Logic Command and peer Datalink 02 as the drive’s Reference. A value of
2 “Custom” enables peer I/O input using the Datalink count and settings provided by the
user.
For detailed information on peer communications, refer to the PowerFlex 755 Drive
Embedded EtherNet/IP Adapter User Manual, publication 750COM-UM001.
Default:
Options:
0 = “Off”
0 = “Off”
1 = “Cmd/Ref”
2 = “Custom”
RW 32-bit
Integer
86 Fr Peer Status
From Peer Status
Displays the status of the consumed Peer I/O input connection.
For detailed information on peer communications, refer to the PowerFlex 755 Drive
Embedded EtherNet/IP Adapter User Manual, publication 750COM-UM001.
Default:
Options:
0 = “Off”
0 = “Off”
1 = “Waiting”
2 = “Running”
3 = “Faulted”
RO 32-bit
Integer
87 DLs To Peer Cfg
Datalinks To Peer Configure
Sets the number of drive-to-network Datalinks (parameters) that are used for Peer I/O.
The Datalinks being used are allocated from the end of the list. For example, if this
parameter's value is set to 3, Datalinks 14…16 are allocated for the three selected
Datalinks. The Datalinks allocated for this cannot overlap with other assigned DL To Net
01…16 parameters.
For detailed information on peer communications, refer to the PowerFlex 755 Drive
Embedded EtherNet/IP Adapter User Manual, publication 750COM-UM001.
Default:
Min/Max:
0
0 / 16
RW 32-bit
Integer
88 DLs To Peer Act
Datalinks To Peer Action
Displays the value of P87 [DLs To Peer Cfg] at the time the drive was reset. This is the
number of actual drive-to-peer Datalinks that the drive is expecting.
Default:
Min/Max:
0
0 / 16
RO 32-bit
Integer
File
Group
No. Display Name
Full Name
Description
Values
Read-Write
Data Type
255 . 255 . 255 . 255
[Peer Inp Addr 1]
[Peer Inp Addr 2]
[Peer Inp Addr 3]
[Peer Inp Addr 4]
