Allen-Bradley PowerFlex 20-750-DCBB2-F6 Programming Manual

250 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 5 Embedded Feature and Option Module Parameters
11-Series I/O
Analog Outputs
82 Anlg Out0 Val
Analog Output 0 Value
Displays the analog output value.
Units:
Default:
Min/Max:
Volt
mA
10.000 Volts
20.000 mA
–/+10.000 Volts
0.000 / 20.000 mA
RO Real
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
11-Series I/O
Predictive Main
99 PredMaint Sts
Predictive Maintenance Status
RO 16-bit
Integer
Status of relay’s predictive maintenance.
(1) Bit 1= “Relay Out 0” for 11-Series I/O Module models 20-750-1132C-2R and 20-750-1132D-2R
100 RO0 Load Type
Relay Output 0 Load Type
Sets the type of load that will be applied to the relay. Must be properly set for the
Predictive Maintenance function to predict the relay life.
Default:
Options:
1 = “DC Inductive”
0 = “DC Resistive”
1 = “DC Inductive”
2 = “AC Resistive”
3 = “AC Inductive”
RW 32-bit
Integer
101 RO0 Load Amps
Relay Output 0 Load Amps
Load current that will be applied to the relay contacts. Must be properly set for the
Predictive Maintenance function to approximate the relay life.
Units:
Default:
Min/Max:
Amps
2.000
0.000 / 2.000
RW Real
102 RO0 TotalLife
Relay Output 0 Total Life
Total life cycles of the relay based on programmed load type and amps.
Units:
Default:
Min/Max:
Cycl
0
0 / 2147483647
RO 32-bit
Integer
103 RO0 ElapsedLife
Relay Output 0 Elapsed Life
Non-resettable, total accumulated cycles of the relay.
Units:
Default:
Min/Max:
Cycl
0
0 / 2147483647
RO 32-bit
Integer
104 RO0 RemainLife
Relay Output 0 Remaining Life
The difference between the Total Life and the Elapsed Life.
Units:
Default:
Min/Max:
Cycl
0
0 / 2147483647
RO 32-bit
Integer
105 RO0 LifeEvntLvl
Relay Output 0 Life Event Level
Sets the percentage of relay life cycles before action is taken.
Units:
Default:
Min/Max:
%
80.000
0.000 / 100.000
RW Real
Options
Master Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Relay Out 0
(1)
Relay Out 0
Default0000000000000000
Bit 1514131211109876543210
0 = Condition False
1 = Condition True
