44 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 2 Parameter Organization
Single Incremental Encoder Module
Parameter descriptions begin on page 263.
Dual Incremental Encoder Module
Parameter descriptions begin on page 266.
File Group Parameters
Single
Incremental
Encoder Host
Groups
N/A Encoder Cfg 1
Encoder PPR 2
Fdbk Loss Cfg 3
Encoder Feedback 4
Encoder Status 5
Error Status 6
Phase Loss Count 7
Quad Loss Count 8
Single Incremental
File Group Parameters
Dual Incremental
Encoder Host
Groups
Encoder 0 Enc 0 Cfg 1
Enc 0 PPR 2
Enc 0 FB Lss Cfg 3
Enc 0 FB 4
Enc 0 Sts 5
Enc 0 Error Sts 6
Enc 0 PhsLss Cnt 7
Enc 0 QuadLssCnt 8
Encoder 1 Enc 1 Cfg 11
Enc 1 PPR 12
Enc 1 FB Lss Cfg 13
Enc 1 FB 14
Enc 1 Sts 15
Enc 1 Error Sts 16
Enc 1 PhsLss Cnt 17
Enc 1 QuadLssCnt 18
Homing Cfg Homing Cfg 20
Module Status Module Sts 21
Dual Incremental
