22 Rockwell Automation Publication 750-UM003D-EN-P - March 2017
Chapter 2 Installation and Wiring
Safety Enable Jumper Locations
See Figure 4 for the location of the safety enable jumper on the main control
board of the PowerFlex 750-Series drives and 755T drive products.
Figure 4 - Safety Enable Jumper Locations on the Main Control Board
IMPORTANT PowerFlex 755 floor mount Frame 8 drives and larger do not have a safety
enable jumper.
PowerFlex 753 Drive
PowerFlex 755 Drive
PowerFlex 755T Drive Products
