Preface
About the PowerFlex
750-Series ATEX Option
Module
The ATEX option module with the 11-Series I/O option module enables a
PowerFlex 750-Series drive and PowerFlex 755T drive products to be used in
ATEX installations. The ATEX option module helps to reduce the risk of
explosion due to an over-temperature condition in an ATEX approved motor.
In an ATEX installation, the motor is installed in a potentially explosive
atmosphere, while the drive is installed outside of the potentially explosive
atmosphere. See Figure 1 on page 11
.
Catalog Numbers for ATEX
and 11-Series I/O Option
Modules
This table lists the catalog numbers for the ATEX option module and the
compatible 11-Series I/O option modules.
Catalog Numbers for Spare
Terminal Plugs
This table contains the catalog numbers for the 11-Series I/O option module
spare terminal plug kits.
WARNING: Risk of Explosion.
Do not install the PowerFlex 750-Series drive or PowerFlex 755T drive products
in a potentially explosive atmosphere.
A drive that is installed in a potentially explosive atmosphere can cause an
explosion.
ATEX Option Module Cat. No. 11-Series I/O Option Module
Cat. No.
Description
20-750-ATEX
20-750-1132D-2R 115V AC digital input
Two relay outputs, digital
20-750-1133C-1R2T 24V DC digital input
Two transistor outputs, one relay output,
digital
20-750-1132C-2R 24V DC digital input
Two relay outputs, digital
Cat. No. Spare Terminal Plug Kit
SK-R1-SCRWTB-EIO Screw-down terminal plugs spare kit (set of three)
SK-R1-SPRGTB-EIO Spring-clamp terminal plugs spare kit (set of three)
