Allen-Bradley PowerFlex 520 Series User Manual

166 Rockwell Automation Publication 520-UM001G-EN-E - September 2014
Appendix B Accessories and Dimensions
200...240V
50/60 Hz
1-Phase
0.25 0.2 1.6 A 25-RF011-AL
0.5 0.4 2.5 A 25-RF011-AL
1.0 0.75 4.8 A 25-RF011-AL
2.0 1.5 8.0 B 25-RF023-BL
3.0 2.2 11.0 B 25-RF023-BL
200...240V
50/60 Hz
3-Phase
0.25 0.2 1.6 A 25-RF014-AL
0.5 0.4 2.5 A 25-RF014-AL
1.0 0.75 5.0 A 25-RF014-AL
2.0 1.5 8.0 A 25-RF014-AL
3.0 2.2 11.0 A 25-RF014-AL
5.0 4.0 17.5 B 25-RF021-BL
7.5 5.5 24.0 C 25-RF027-CL
10.0 7.5 32.2 D 25-RF035-DL
15.0 11.0 48.3 E 25-RF056-EL
20.0 15.0 62.1 E 25-RF056-EL
380...480V
50/60 Hz
3-Phase
0.5 0.4 1.4 A 25-RF7P5-AL
1.0 0.75 2.3 A 25-RF7P5-AL
2.0 1.5 4.0 A 25-RF7P5-AL
3.0 2.2 6.0 A 25-RF7P5-AL
5.0 4.0 10.5 B 25-RF014-BL
7.5 5.5 13.0 C 25-RF018-CL
10.0 7.5 17.0 C 25-RF018-CL
15.0 11.0 24.0 D 25-RF033-DL
20.0 15.0 30.0 D 25-RF033-DL
25.0 18.5 37.0 E 25-RF039-EL
30.0 22.0 43.0 E 25-RF039-EL
(1)
525...600V
50/60 Hz
3-Phase
0.5 0.4 0.9 A 25-RF8P0-BL
(2)
1.0 0.75 1.7 A 25-RF8P0-BL
(2)
2.0 1.5 3.0 A 25-RF8P0-BL
(2)
3.0 2.2 4.2 A 25-RF8P0-BL
(2)
5.0 4.0 6.6 B 25-RF8P0-BL
7.5 5.5 9.9 C 25-RF014-CL
10.0 7.5 12.0 C 25-RF014-CL
15.0 11.0 19.0 D 25-RF027-DL
20.0 15.0 22.0 D 25-RF027-DL
25.0 18.5 27.0 E 25-RF029-EL
30.0 22.0 32.0 E 25-RF029-EL
(1)
(1) EMC Line Filter size is based on the input current of the drive. See the tables on page 25 and page 26 for more information.
(2) This 600V drive rating needs to be matched with a frame B EMC Line Filter.
EMC Plates
Item Description
Frame
Size Catalog No.
EMC Plate Optional grounding plate for shielded cables. A 25-EMC1-FA
B 25-EMC1-FB
C 25-EMC1-FC
D 25-EMC1-FD
E 25-EMC1-FE
EMC Line Filters
Drive Ratings
Frame Size Catalog No.Input Voltage HP kW Current (A)
