Allen-Bradley PowerFlex 520 Series User Manual

Rockwell Automation Publication 520-UM001G-EN-E - September 2014 167
Accessories and Dimensions Appendix B
Human Interface Module (HIM) Option Kits and Accessories
Item Description Catalog No.
LCD Display, Remote Panel
Mount
Digital speed control
CopyCat capable
IP66 (NEMA Type 4X/12) indoor use only
Includes 2.9 meter cable
22-HIM-C2S
LCD Display, Remote
Handheld
Digital speed control
Full numeric keyboard
CopyCat capable
IP 30 (NEMA Type 1)
Includes 1.0 meter cable
Panel mount with optional Bezel Kit
22-HIM-A3
Bezel Kit Panel mount for LCD Display, Remote Handheld unit, IP 30 (NEMA Type 1)
Includes 2.0 m DSI cable
22-HIM-B1
DSI HIM Cable
(DSI HIM to RJ45 cable)
1.0 m (3.3 ft) 22-HIM-H10
2.9 m (9.51 ft) 22-HIM-H30
IP 30/NEMA 1/UL Type 1 Kit
Item Description
Frame
Size Catalog No.
IP 30/NEMA 1/UL Type 1 Kit Field installed kit. Converts drive to IP 30/NEMA 1/UL Type 1
enclosure. Includes conduit box with mounting screws and
plastic top panel.
A25-JBAA
B25-JBAB
C25-JBAC
D25-JBAD
E25-JBAE
Control Module Fan Kit
Item Description
Frame
Size Catalog No.
Control Module Fan Kit For use with drive in environments with ambient
temperatures up to 70 °C or horizontal mounting.
A...D 25-FAN1-70C
E 25-FAN2-70C
Incremental Encoder Input Option
Item Description Catalog No.
Incremental Encoder Incremental encoder input option board. 25-ENC-1
Bulletin 160 to PowerFlex 520-Series Mounting Adapter Plate
Item Description
B160
Frame
Size Catalog No.
Mounting Adapter Plate For use with drive when replacing Bulletin 160 drives in
existing installations to a PowerFlex 520-Series drive. Select
the catalog number based on the frame size of your Bulletin
160 drive.
A 25-MAP-FA
B 25-MAP-FB
