Publication 20A-IN009C-EN-P
28 PowerFlex® 70 Adjustable Frequency AC Drive Installation Instructions
Table J I/O Terminal Designations – Standard and Enhanced Control
No. Signal
Factory
Default
Description
Related
Param.
1 Digital In 1 Stop – CF
(CF = Clear
Fault)
11.2 mA @ 24V DC
19.2V minimum on state
3.2V maximum off state
Important: Use only 24V DC, not suitable for
115V AC circuitry.
Inputs can be wired as sink or source.
361 -
366
2 Digital In 2 Start
3 Digital In 3 Auto/Man
4 Digital In 4 Speed Sel 1
5 Digital In 5 Speed Sel 2
6 Digital In 6 Speed Sel 3
7 24V Common – Drive supplied power for Digital In1…6 inputs only.
Not intended for use on circuits outside of the
drive.
150 mA maximum load.
8 Digital In Common –
9 +24V DC –
10 +10V DC Pot Reference – 2 k ohm minimum load.
11 Digital Out 1 – N.O.
(1)
NOT Fault Max Resistive Load
250V AC / 30V DC
50VA / 60 W
Minimum DC Load
10 µA, 10 mV DC
Max Inductive Load
250V AC / 30V DC
25 VA / 30 W
380 -
387
12 Digital Out 1 Common
13 Digital Out 1 – N.C.
(1)
Fault
14 Analog In 1 (– Volts)
(2)
TB Man Ref
Voltage –
Reads value
at 14 & 15
Non-isolated, 0 to +10V, 10 bit, 100k ohm input
impedance.
(3)
320 -
327
15 Analog In 1 (+ Volts)
16 Analog In 1 (– Current) Non-isolated, 0-20 mA, 10 bit, 100 ohm input
impedance.
(3)
17 Analog In 1 (+ Current)
18 Analog In 2 (– Volts)
(2)
Speed Ref A
Voltage –
Reads value
at 18 & 19
Isolated, bipolar, differential, 0 to +10V unipolar
(10 bit) or ±10V bipolar (10 bit & sign), 100k ohm
input impedance.
(4)
19 Analog In 2 (+ Volts)
20 Analog In 2 (– Current) Isolated, 0-20 mA, 10 bit & sign, 100 ohm input
impedance.
(4)
21 Analog In 2 (+ Current)
22 10V Pot Common
Analog Out (– Volts)
Analog Out (– Current)
(2)
Output Freq
0 to +10V, 10 bit, 10k ohm (2k ohm minimum)
load.
0 to 20 mA, 10 bit, 400 ohm maximum load.
(5)
Referenced to chassis ground.
Common if internal 10V supply (terminal 10) is
used.
340 -
344
23 Analog Out (+ Volts)
Analog Out (+ Current)
24 Digital Out 2 – N.O.
(1)
Run See description at No.s 11…13. 380 -
387
25 Digital Out 2 Common
26 Digital Out 2 – N.C.
(1)
NOT Run
(1) Contacts shown in unpowered state. Any relay programmed as Fault or Alarm will energize (pick
up) when power is applied to drive and deenergize (drop out) when fault or alarm exists. Relays
selected for other functions will energize only when that condition exists and will deenergize when
condition is removed.
(2) These inputs/outputs are dependent on a number of parameters. See “Related Parameters.”
(3) Differential Isolation - External source must be less than 10V with respect to PE.
(4) Differential Isolation - External source must be maintained at less than 160V with respect to PE.
Input provides high common mode immunity.
(5) Analog output current is only available with Enhanced Control drives.
