Allen-Bradley PowerFlex 70 - Catalog Number Explanation; Qualified Personnel; Read the General Precautions; Step 1

Publication 20A-IN009C-EN-P
4 PowerFlex® 70 Adjustable Frequency AC Drive Installation Instructions
Qualified Personnel
Catalog Number Explanation
Position Number
1-3 45-78 9 10111213141516
20A B 2P2 A 3 A Y Y N N C 0
abcdefghi jkl
a
Drive
Code Type
20A PowerFlex 70
b
Voltage Rating
Code Voltage Ph.
B 240V ac 3
C 400V ac 3
D 480V ac 3
E 600V ac 3
c
ND Output Rating for Voltage Rating
Examples:
Code Amps kW (Hp)
2P2 2.2 0.37 (0.5)
022 22 5.5 (7.5)
e
HIM
Code Interface Module
0 Blank Cover
3 Full Numeric LCD
5 Prog. Only LCD
8
Wireless Interface Module -
IP66, NEMA/UL Type 4X/12
Only
g
Brake IGBT
Code w/Brake IGBT
seYY
h
Internal Brake Resistor
Code w/Resistor
seYY
oNN
l
Feedback
Code Feedback
N NA - Standard Control
0
No Feedback - Enhanced
Control
1
5V/12V Encoder w/Enhanced
Control
j
Comm Slot
Code Version
B BACnet
C ControlNet (Coax)
D DeviceNet
E EtherNet/IP
OIRR
S RS485 DF1
N None
d
Enclosure
Code Enclosure
A
Panel Mount - IP 20, NEMA/UL
Type 1
C
Wall/Machine Mount = IP66,
NEMA/UL Type 4X/12 for
indoor use only
F
Flange Mount - Front Chassis =
IP 20, NEMA/UL Type 1; Rear
Heatsink = IP66, NEMA/UL
Type 4X/12 for indoor/outdoor
use
G
Wall/Machine Mount - IP54,
NEMA/UL Type 12
L
Flange Mount with Conformal
Coat
M
Panel Mount with Conformal
Coat
Only available on Frame E.
f
Documentation
Code Type
A Manual
N No Manual
i
Emission Class
Code Rating
A
Filtered
A & B Frames (Optional)
C, D, & E Frames (Standard)
N
Not Filtered
A & B Frames (Optional)
C, D, & E Frames
600V Frames A through D available only
without filter (Cat. Code N). 600V Frame E
available only with filter (Cat. Code A).
Increases size to Frame B.
k
Control & I/O
Code Control Safe-Off
N Standard N/A
C Enhanced No
G
Enhanced Yes
Not available as factory installed option for
600V ratings.
Step 1 Read the General Precautions
!
ATTENTION: Only qualified personnel familiar with adjustable
frequency AC drives and associated machinery should plan or
implement the installation, start-up and subsequent maintenance of the
system. Failure to comply may result in personal injury and/or
equipment damage.
