Publication 20A-IN009C-EN-P
38 PowerFlex® 70 Adjustable Frequency AC Drive Installation Instructions
Human Interface Module (HIM) Main Menu
ALT Functions
To use an ALT function, start at the Main Menu and press the ALT key,
release it, then press the programming key associated with one of the
following functions:
Main Menu Screen Menu Selections
Main Menu:
Diagnostics
Parameter
Device Select
Memory Storage
Start-Up
Preferences
ALT Key then Function Function Description
S.M.A.R.T. Displays the S.M.A.R.T. screen. This function allows the
drive parameter values to be quickly programed by
directly accessing the most frequently used drive
functions. Refer to the User Manual for more
information.
Log In/Out Log in to change parameter settings.
Log out to protect parameter settings.
Change a password.
View Allows the selection of how parameters will be viewed
or detailed information about a parameter or
component.
Device Select a connected adapter for editing.
Lang Displays the language selection screen. The LCD
Human Interface Module (HIM) on an architecture class
drive allows you to change the display language any
time.
Auto / Man Switches between Auto and Manual Modes. If the
Human Interface Module (HIM) requests Manual Mode,
the Speed Reference source is transferred to the
Human Interface Module (HIM).
Remove Allows Human Interface Module (HIM) removal without
causing a fault if the Human Interface Module (HIM) is
not the last controlling device and does not have
Manual control of the drive.
Param # Allows entry of a parameter number for viewing/editing.
F-> Power Loss Auto
0.0
Hz
Main Menu:
Diagnostics
Parameter
Device Select
ALT
Esc
Esc
Sel
Sel
+/–
To Next Page
