Publication 20A-IN009C-EN-P
40 PowerFlex® 70 Adjustable Frequency AC Drive Installation Instructions
During a Start Up, the majority of applications require changes to only a
few parameters. The LCD HIM on a PowerFlex 70 drive offers
S.M.A.R.T. start, which displays the most commonly changed
parameters. With these parameters, you can set the following functions:
S - Start Mode and Stop Mode
M - Minimum and Maximum Speed
A - Accel Time 1 and Decel Time 1
R - Reference Source
T - Thermal Motor Overload
To run a S.M.A.R.T. start routine:
Important: This start-up routine requires an LCD HIM.
The Assisted start-up routine prompts you to input required information.
Access Assisted Start Up by selecting “Start Up” from the Main Menu.
To perform an Assisted Start-Up:
Important: Done/Exit must be selected upon completion of the Start
Up routine in order for any Start Up/Autotune data to be
saved.
Running S.M.A.R.T. Start
Step Key(s) Example LCD Displays
1. Press ALT and then Esc (S.M.A.R.T). The
S.M.A.R.T. start screen appears.
2. View and change parameter values as
desired. For HIM information, see
Appendix B.
3. Press Esc to exit the S.M.A.R.T. start.
ALT
Esc
Esc
F-> Stopped Auto
0.0
Hz
Main Menu:
Diagnostics
Parameter
SMART List:
Digital In2 Sel
Stop Mode A
Minimum Speed
Running an Assisted Start Up
Step Key(s) Example LCD Displays
1. In the Main Menu, press the Up Arrow or
Down Arrow to scroll to “Start Up”.
2. Press Enter.
F-> Stopped Auto
0.0
Hz
Main Menu:
Memory Storage
Start Up
Preferences
