Publication 20A-IN009C-EN-P
50 PowerFlex® 70 Adjustable Frequency AC Drive Installation Instructions
296 MOP Owner Masks & Owners
297 Local Owner Masks & Owners
298 DPI Ref Select Comm Control
300-307 Data In XX Datalinks
308 HighRes Ref Datalinks
310-317 Data Out XX Datalinks
320 Anlg In Config Analog Inputs
321 Anlg In Sqr Root Analog Inputs
322, 325 Analog In X Hi Analog Inputs
323, 326 Analog In X Lo Analog Inputs
324, 327 Analog In X Loss Analog Inputs
340 Anlg Out Config Analog Outputs
341 Anlg Out Absolut Analog Outputs
342 Analog Out1 Sel Analog Outputs
343 Analog Out1 Hi Analog Outputs
344 Analog Out1 Lo Analog Outputs
354 Anlg Out1 Scale Analog Outputs
361-366 Digital InX Sel Digital Inputs
377 Anlg Out1 Setpt Analog Outputs
379 Dig Out Setpt Digital Outputs
380, 384 Digital OutX Sel Digital Outputs
381, 385 Dig OutX Level Digital Outputs
382, 386 Dig OutX OnTime Digital Outputs
383, 387 Dig OutX OffTime Digital Outputs
411 DigIn DataLogic Digital Inputs
412 Motor Fdbk Type** Speed Feedback
413 Encoder PPR** Speed Feedback
414 Enc Pos Feedback Speed Feedback
415 Encoder Speed Speed Feedback
416 Fdbk Filter Sel** Speed Feedback
419 Notch FilterFreq** Speed Feedback
420 Notch Filter K** Speed Feedback
427 Torque Ref A Sel** Torq Attributes
428 Torque Ref A Hi** Torq Attributes
429 Torque Ref A Lo** Torq Attributes
435 Torque Setpoint1** Torq Attributes
436 Pos Torque Limit** Torq Attributes
437 Neg Torque Limit** Torq Attributes
440 Control Status Torq Attributes
441 Torq Current Ref Torq Attributes
445 Ki Speed Loop** Speed Regulator
446 Kp Speed Loop** Speed Regulator
447 Kf Speed Loop** Speed Regulator
448 Spd Err Filt BW
3.x
Speed Regulator
449 Speed Desired BW** Speed Regulator
450 Total Inertia** Speed Regulator
451 Speed Loop Meter** Speed Regulator
454 Rev Speed Limit Spd Mode & Limits
459 PI Deriv Time Process PI
460 PI Reference Hi Process PI
461 PI Reference Lo Process PI
462 PI Feedback Hi Process PI
463 PI Feedback Lo Process PI
Number Parameter Name Group
* These parameters will only be displayed
when parameter 053 [Motor Cntl Sel] is set
to option “2 or 3.”
** These parameters will only
be displayed
when parameter 053 [Motor Cntl Sel] is set
to option “4.”
3.x
Firmware 3.002 & later only.
476, 482 ScaleX In Value Scaled Blocks
477, 483 ScaleX In Hi Scaled Blocks
478, 484 ScaleX In Lo Scaled Blocks
595 Port Mask Act Security
596 Write Mask Cfg Security
597 Write Mask Act Security
598 Logic Mask Act Security
620 Fiber Control Fiber Functions
3.x
621 Fiber Status Fiber Functions
3.x
622 Sync Time Fiber Functions
3.x
623 Traverse Inc Fiber Functions
3.x
624 Traverse Dec Fiber Functions
3.x
625 Max Traverse Fiber Functions
3.x
626 P Jump Fiber Functions
3.x
Number Parameter Name Group
