Allen-Bradley powerflex 700 Technical Data

PowerFlex 700 Technical Data
16 20B-TD001F-EN-P
600V, 60 Hz, Three-Phase, 5% Impedance
Drive Cat. No. Duty Hp
Input Line Reactor
(1)
(1)
Input line reactors were sized based on the NEC fundamental motor amps. Output line reactors were sized based on the VFD rated output currents.
Output Line Reactor
(1)
IP00 (Open Style) IP11 (NEMA/UL Type 1) IP00 (Open Style) IP11 (NEMA/UL Type 1)
Cat. No. Cat. No. Cat. No. Cat. No.
20BE1P7 Heavy Duty 0.5 1321-3R1-B 1321-3RA1-B 1321-3R2-C 1321-3RA2-C
20BE1P7 Normal Duty 1 1321-3R2-C 1321-3RA2-C 1321-3R2-C 1321-3RA2-C
20BE2P7 Heavy Duty 1 1321-3R2-C 1321-3RA2-C 1321-3R4-D
(2)
1321-3RA4-D
(2)
20BE2P7 Normal Duty 2 1321-3R4-D
(2)
1321-3RA4-D
(2)
1321-3R4-D
(2)
1321-3RA4-D
(2)
20BE3P9 Heavy Duty 2 1321-3R4-D
(2)
1321-3RA4-D
(2)
1321-3R4-D 1321-3RA4-D
20BE3P9 Normal Duty 3 1321-3R4-D 1321-3RA4-D 1321-3R4-D 1321-3RA4-D
20BE6P1 Heavy Duty 3 1321-3R4-D 1321-3RA4-D 1321-3R8-D 1321-3RA8-D
20BE6P1 Normal Duty 5 1321-3R8-D 1321-3RA8-D 1321-3R8-D 1321-3RA8-D
20BE9P0 Heavy Duty 5 1321-3R8-D 1321-3RA8-D 1321-3R12-C
(2)
1321-3RA12-C
(2)
20BE9P0 Normal Duty 7.5 1321-3R12-C
(2)
(2)
4% impedance.
1321-3RA12-C
(2)
1321-3R12-C
(2)
1321-3RA12-C
(2)
20BE011 Heavy Duty 7.5 1321-3R12-C
(2)
1321-3RA12-C
(2)
1321-3R12-C 1321-3RA12-C
20BE011 Normal Duty 10 1321-3R12-C 1321-3RA12-C 1321-3R12-C 1321-3RA12-C
20BE017 Heavy Duty 10 1321-3R12-C 1321-3RA12-C 1321-3R18-C 1321-3RA18-C
20BE017 Normal Duty 15 1321-3R18-C 1321-3RA18-C 1321-3R18-C 1321-3RA18-C
20BE022 Heavy Duty 15 1321-3R18-C 1321-3RA18-C 1321-3R25-C
(2)
1321-3RA25-C
(2)
20BE022 Normal Duty 20 1321-3R25-C
(2)
1321-3RA25-C
(2)
1321-3R25-C
(2)
1321-3RA25-C
(2)
20BE027 Heavy Duty 20 1321-3R25-C
(2)
1321-3RA25-C
(2)
1321-3R35-C
(2)
1321-3RA35-C
(2)
20BE027 Normal Duty 25 1321-3R35-C
(2)
1321-3RA35-C
(2)
1321-3R35-C
(2)
1321-3RA35-C
(2)
20BE032 Heavy Duty 25 1321-3R35-C
(2)
1321-3RA35-C
(2)
1321-3R35-C
(2)
1321-3RA35-C
(2)
20BE032 Normal Duty 30 1321-3R35-C
(2)
1321-3RA35-C
(2)
1321-3R35-C
(2)
1321-3RA35-C
(2)
20BE041 Heavy Duty 30 1321-3R35-C
(2)
1321-3RA35-C
(2)
1321-3R45-C 1321-3RA45-C
20BE041 Normal Duty 40 1321-3R45-C 1321-3RA45-C 1321-3R45-C 1321-3RA45-C
20BE052 Heavy Duty 40 1321-3R45-C 1321-3RA45-C 1321-3R55-C 1321-3RA55-C
20BE052 Normal Duty 50 1321-3R55-C 1321-3RA55-C 1321-3R55-C 1321-3RA55-C
20BE062 Heavy Duty 50 1321-3R55-C 1321-3RA55-C 1321-3R80-C 1321-3RA80-C
20BE062 Normal Duty 60 1321-3R80-C 1321-3RA80-C 1321-3R80-C 1321-3RA80-C
20BE077 Heavy Duty 60 1321-3R80-C 1321-3RA80-C 1321-3R80-C 1321-3RA80-C
20BE077 Normal Duty 75 1321-3R80-C 1321-3RA80-C 1321-3R80-C 1321-3RA80-C
20BE099 Heavy Duty 75 1321-3R80-C 1321-3RA80-C 1321-3R80-C 1321-3RA80-C
20BE099 Normal Duty 100 1321-3R100-C 1321-3RA100-C 1321-3R100-C 1321-3RA100-C
20BE125 Heavy Duty 100 1321-3R100-C 1321-3RA100-C 1321-3R100-C 1321-3RA100-C
20BE125 Normal Duty 125 1321-3R130-C
(2)
1321-3RA130-C
(2)
1321-3R130-C
(2)
1321-3RA130-C
(2)
20BE144 Heavy Duty 125 1321-3R130-C
(2)
1321-3RA130-C
(2)
1321-3R130-C
(2)
1321-3RA130-C
(2)
20BE144 Normal Duty 150 1321-3R160-C
(2)
1321-3RA160-C
(2)
1321-3R160-C
(2)
1321-3RA160-C
(2)

Allen-Bradley powerflex 700 Specifications

General

Series	PowerFlex 700
Category	AC Drive
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Enclosure	Type 1
Control Method	Sensorless Vector
Communication	EtherNet/IP, ControlNet, DeviceNet, PROFIBUS DP, Modbus
