PowerFlex 700 Technical Data
20B-TD001F-EN-P 37
325 Volt DC Input Protection Devices (See page 39 for Notes)
540 Volt DC Input Protection Devices (See page 39 for Notes)
Drive
Catalog
Number
Frame
Hp Rating
PWM
Freq.
Temp.
(1)
DC Input
Ratings Output Amps
Fuse
Non-Time
Delay Fuse
(2)
ND HD kHz °C Amps Cont. 1 Min. 3 Sec.
325 Volt DC Input
20BB2P2 0 0.5 0.33 4 50 2 2.2 2.4 3.3 5 JKS-5
20BB4P2 0 1 0.75 4 50 3.8 4.2 4.8 6.4 10 JKS-10
20BB6P8 1 2 1.5 4 50 6.9 6.8 9 12 15 HSJ15
20BB9P6 1 3 2 4 50 9.7 9.6 10.6 14.4 20 HSJ20
20BB015 1 5 3 4 50 16 15.3 16.8 23 30 HSJ30
20BB022 1 7.5 5 4 50 23.3 22 24.2 33 45 HSJ45
20BB028 2 10 7.5 4 50 30 28 33 44 60 HSJ60
20BB042 3 15 10 4 50 45 42 46.2 63 90 HSJ90
20BB052 3 20 15 4 50 55 52 63 80 100 HSJ100
20BB070 4 25 20 4 50 75.3 70 78 105 150 HSJ150
20BB080 4 30 25 4 50 86.8 80 105 140 175 HSJ175
20BN104
(3)
5 40 – 4 50 114.1 104 115 175 200 HSJ200
– 30 4 50 85.8 80 120 160 200 HSJ200
20BN130
(3)
5 50 – 4 50 142.6 130 143 175 200 HSJ200
– 40 4 50 114.1 104 156 175 200 HSJ200
20BN154
(3)
6 60 – 4 50 169 154 169 231 300 HSJ300
– 50 4 50 142.6 130 195 260 300 HSJ300
20BN192
(3)
6 75 – 4 50 210.6 192 211 288 350 HSJ350
– 60 4 50 169 154 231 308 350 HSJ350
20BN260
(3)
6 100 – 2 45 285.3 260 286 390 400 HSJ400
– 75 2 50 210.6 205 305 410 400 HSJ400
Drive Catalog
Number
Frame
kW Rating
PWM
Freq.
Temp.
(1)
DC Input
Ratings Output Amps
Fuse
Non-Time
Delay
Fuse
(2)
ND HD kHz °C Amps kW Cont. 1 Min. 3 Sec.
540 Volt DC Input
20BC1P3 0 0.37 0.25 4 50 1.3 1.3 1.4 1.9 3 JKS-3
20BC2P1 0 0.75 0.55 4 50 2.1 2.1 2.4 3.2 6 JKS-6
20BC3P5 0 1.5 0.75 4 50 3.7 3.5 4.5 6 8 JKS-8
20BC5P0 0 2.2 1.5 4 50 5.3 5 5.5 7.5 10 JKS-10
20BC8P7 0 4 3 4 50 9.3 8.7 9.9 13.2 15 HSJ15
20BC011 0 5.5 4 4 50 12.6 11.5 13 17.4 20 HSJ20
20BC015 1 7.5 5.5 4 50 16.8 15.4 17.2 23.1 25 HSJ25
20BC022 1 11 7.5 4 50 24 22 24.2 33 40 HSJ40
20BC030 2 15 11 4 50 33.2 30 33 45 50 HSJ50
20BC037 2 18.5 15 4 50 40.9 37 45 60 70 HSJ70
20BC043 3 22 18.5 4 50 47.5 43 56 74 90 HSJ90
20BC056 3 30 22 4 50 61.9 56 64 86 100 HSJ100
20BC072 3 37 30 4 50
(7)
80.5 72 84 112 125 HSJ125
20BC085
(3)(5)
4 45 – 4 45 95.1 85 94 128 150 HSJ150
– 37 4 45 80.5 72 108 144 175 HSJ175
20BH105
(3)(5)
5 55 – 4 50
(4)
120.2 105 116 158 175 HSJ175
– 45 4 50
(4)
95.1 85 128 170 200 HSJ200
20BH140
(3)(5)
575 – 4 40
(4)
159 140 154 190 225 HSJ225
–554 40
(4)
120.2 105 158 190 225 HSJ225
20BH170
(3)(5)
6 90 – 4 50
(4)
192.3 170 187 255 300 HSJ300
– 75 4 50
(4)
159 140 210 280 300 HSJ300
20BH205
(3)(5)
6 110 – 4 40
(4)
226 205 220 289 350 HSJ350
–904 40
(4)
192.3 170 255 313 350 HSJ350
20BH260
(3)(5)
6 132 – 2 45
(4)
298 260 286 390 500 HSJ500
– 110 2 50
(4)
226 205 305 410 500 HSJ500
20BP292 7 160 4 40 342 185 292 322 438 500 170M6608
(10)
150 4 40 309 166 263 395 526 630 170M6610
(10)
20BP325 7 180 4 40 381 206 325 358 488 630 170M6610
(10)
180 4 40 381 206 325 488 650 800 170M6612
(10)
20BP365 8 200 2 40 428 231 365 402 548 630 170M6610
(10)
180 2 40 381 206 325 488 650 800 170M6612
(10)
20BP415 8 240 2 40 487 262 415 457 623 800 170M6612
(10)
200 2 40 428 231 365 548 730 900 170M6613
(10)
20BP481 8 280 2 40 564 304 481 530 722 900 170M6613
(10)
240 2 40 487 262 415 623 830 1000 170M6614
(10)
20BP535 8 300 2 40 627 338 535 589 803 1000 170M6614
(10)
280 2 40 564 304 481 722 962 1100 170M6615
(10)

Allen-Bradley powerflex 700 Specifications

General

Series	PowerFlex 700
Category	AC Drive
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Enclosure	Type 1
Control Method	Sensorless Vector
Communication	EtherNet/IP, ControlNet, DeviceNet, PROFIBUS DP, Modbus
