PowerFlex 700 Technical Data
36 20B-TD001F-EN-P
600 Volt AC Input Protection Devices
(13)
690 Volt AC Input Protection Devices
(13)
Notes:
(1)
Minimum protection device size is the lowest rated device that supplies maximum protection without nuisance tripping.
(2)
Maximum protection device size is the highest rated device that supplies drive protection. For US NEC, minimum size is 125% of motor FLA. Ratings shown are maximum.
(3)
Circuit Breaker - inverse time breaker. For US NEC, minimum size is 125% of motor FLA. Ratings shown are maximum.
(4)
Motor Circuit Protector - instantaneous trip circuit breaker. For US NEC minimum size is 125% of motor FLA. Ratings shown are maximum.
(5)
Bulletin 140M with adjustable current range should have the current trip set to the minimum range that the device will not trip.
(6)
Manual Self-Protected (Type E) Combination Motor Controller, UL listed for 208 Wye or Delta, 240 Wye or Delta, 480Y/277 or 600Y/ 347. Not UL listed for use on 480V or 600V Delta/Delta
systems.
(7)
The AIC ratings of the Bulletin 140M Motor Protector may vary. See publication 140M-SG001B-EN-P.
(8)
Maximum allowable rating by US NEC. Exact size must be chosen for each installation.
(9)
UL Type 12/IP54 (flange mount) heat sink ambient temperature rating is 40 °C/ambient of unprotected drive portion (inside enclosure) is 55 °C. The ambient temperature for the UL Type 12/
IP54 stand-alone drives is 40 °C.
(10)
Must remove top label and vent plate, drive enclosure rating will be IP00, NEMA/UL Type Open.
(11)
Drive frames 0-4 temperature rating is for NEMA/UL Type Open. The adhesive top label must be removed to operate drive at this temperature. Frames 5 & 6 do not have a top label.
(12)
Drives have dual current ratings; one for normal duty applications, and one for heavy duty applications. The drive may be operated at either rating.
(13)
Frame 7…10 drives are CE Certified for use with 400V AC and 480V AC center grounded neutral power supply systems only. 600V class drives below 77 Amps (Frames 0…4) are declared
to meet the Low Voltage Directive. It is the responsibility of the user to determine compliance to the EMC directive.
(14)
Temperature rating is for IP20, NEMA/UL Type 1. For IP00, NEMA Type Open the temperature rating is 65 °C for the control board and 40 °C for the heat sink entry air.
Drive
Catalog
Number
Frame
Hp
Rating
PWM
Freq.
Temp.
(11)
Input
Ratings Output Amps
Dual
Element Time
Delay Fuse
Non-Time
Delay Fuse
Circuit
Breaker
(3)
Motor
Circuit
Protector
(4)
140M Motor Protector with Adjustable Current
Range
(5)(6)
ND HD kHz °C Amps kVA Cont. 1 Min. 3 Sec. Min.
(1)
Max.
(2)
Min.
(1)
Max.
(2)
Max.
(8)
Max.
(8)
Available Catalog Numbers - 140…
(7)
600 Volt AC Input
20BE1P7 0 1 0.5 4 50 1.3 1.4 1.7 2 2.6 2 4 2 6 15 3 M-C2E-B16 – – –
20BE2P7 0 2 1 4 50 2.1 2.1 2.7 3.6 4.8 3 6 3 10 15 3 M-C2E-B25 – – –
20BE3P9 0 3 2 4 50 3 3.1 3.9 4.3 5.9 6 9 6 15 15 7 M-C2E-B40 M-D8E-B40 – –
20BE6P1 0 5 3 4 50 5.3 5.5 6.1 6.7 9.2 9 12 9 20 20 15 M-C2E-B63 M-D8E-B63 – –
20BE9P0 0 7.5 5 4 50 7.8 8.1 9 9.9 13.5 10 20 10 35 30 15 M-C2E-C10 M-D8E-C10 M-F8E-C10 –
20BE011 1 10 7.5 4 50 9.9 10.2 11 13.5 18 15 25 15 40 40 15 M-C2E-C10 M-D8E-C10 M-F8E-C10 –
20BE017 1 15 10 4 50 15.4 16 17 18.7 25.5 20 40 20 60 50 20 M-C2E-C16 M-D8E-C16 M-F8E-C16 –
20BE022 2 20 15 4 50 20.2 21 22 25.5 34 30 50 30 80 80 30 M-C2E-C25 M-D8E-C25 M-F8E-C25 -CMN-2500
20BE027 2 25 20 4 50 24.8 25.7 27 33 44 35 60 35 100 100 50 – – M-F8E-C25 -CMN-2500
20BE032 3 30 25 4 50 29.4 30.5 32 40.5 54 40 70 40 125 125 50 – – M-F8E-C32 -CMN-4000
20BE041 3 40 30 4 50 37.6 39.1 41 48 64 50 90 50 150 150 100 – – M-F8E-C45 -CMN-4000
20BE052 3 50 40 4 50 47.7 49.6 52 61.5 82 60 110 60 200 200 100 – – – -CMN-6300
20BE062 4 60 50 2 50 58.2 60.5 62 78 104 80 125 80 225 225 100 – – – -CMN-6300
20BE077
(12)
575 – 2 50
(9)
72.3 75.1 77 85 116 90 150 90 300 300 100 – – – -CMN-9000
–602 50
(9)
58.2 60.5 63 94 126 90 125 90 250 250 100 – – – -CMN-6300
20BE099
(12)
5 100 – 2 40
(9)
92.9 96.6 99 109 126 125 200 125 375 375 150 – – – –
– 75 2 40
(9)
72.3 75.1 77 116 138 100 175 100 300 300 100 – – – -CMN-9000
20BE125
(12)
6 125 – 2 50
(9)
117 122 125 138 188 150 250 150 375 375 250 – – – –
– 100 2 50
(9)
93 96.6 99 149 198 125 200 125 375 375 150 – – – –
20BE144
(12)
6 150 – 2 50
(9)
135 141 144 158 216 175 300 175 400 400 250 – – – –
– 125 2 50
(9)
117 122 125 188 250 150 275 150 375 375 250 – – – –
Drive
Catalog
Number
Frame
kW
Rating
PWM
Freq. Temp.
(11)
Input
Ratings Output Amps
Dual
Element Time
Delay Fuse
Non-Time
Delay Fuse
Circuit
Breaker
(3)
Motor
Circuit
Protector
(4)
ND HD kHz °C Amps kVA Cont. 1 Min. 3 Sec. Min.
(1)
Max.
(2)
Min.
(1)
Max.
(2)
Max.
(8)
Max.
(8)
690 Volt AC Input
20BF052
(12)
5 45 – 4 50
(9)
46.9 56.1 52 57 78 60 110 60 175 175 –
– 37.5 4 50
(9)
40.1 48 46 69 92 50 90 50 150 150 –
20BF060
(12)
555 – 4 50
(9)
57.7 68.9 60 66 90 80 125 80 225 225 –
–454 50
(9)
46.9 56.1 52 78 104 60 110 60 175 175 –
20BF082
(12)
5 75 – 2 50
(9)
79 94.4 82 90 123 100 200 100 375 375 –
– 55 2 50
(9)
57.7 68.9 60 90 120 80 125 80 225 225 –
20BF098
(12)
590 – 2 40
(9)
94.7 113 98 108 127 125 200 125 375 375 –
–752 40
(9)
79 94.4 82 123 140 100 200 100 375 375 –
20BF119
(12)
6 110 – 2 50
(9)
115 137 119 131 179 150 250 150 400 – –
– 90 2 50
(9)
94.7 113 98 147 196 125 200 125 375 – –
20BF142
(12)
6 132 – 2 50
(9)
138 165 142 156 213 175 300 175 450 – –
– 110 2 50
(9)
115 137 119 179 238 150 250 150 400 – –
