Allen-Bradley powerflex 700 Technical Data

PowerFlex 700 Technical Data
20B-TD001F-EN-P 49
Frame 5
Dimensions are in millimeters and (inches)
Frame
(1)
(1)
Refer to page 47 for frame information.
A (Max.) BC (Max.) DE
Approx. Weight
(2)
kg (lbs.)
(2)
Weights include HIM and Standard I/O. Add 2.70 kg (6.0 lbs.) for the 20BC140 drive.
Drive
Drive &
Packaging
5 308.9 (12.16) 644.5 (25.37)
(3)
(3)
When using the supplied junction box (100 Hp drives Only), add an additional 45.1 mm (1.78 in.) to this dimension.
275.4 (10.84) 225.0 (8.86) 625.0 (24.61) 37.19 (82.0) 49.50 (109.0)
HOT surfaces can cause severe burns
CAUTION
E
12.5
(0.49)
6.5 (0.26)
B
D
A
259.1 (10.20)
Detail
15.0 (0.59)
6.5 (0.26)
37.6 (1.48)
C
Lifting Holes - 4 Places
12.7 (0.50) Dia.

Allen-Bradley powerflex 700 Specifications

General

Series	PowerFlex 700
Category	AC Drive
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Enclosure	Type 1
Control Method	Sensorless Vector
Communication	EtherNet/IP, ControlNet, DeviceNet, PROFIBUS DP, Modbus
