PowerFlex 700 Technical Data
74 20B-TD001F-EN-P
Watts Loss (Rated Load, Speed & PWM)
(1)
IP20, NEMA/UL Type 1 – Frames 0…6 IP54, NEMA/UL Type 12 – Frames 0…6
IP20, NEMA/UL Type 1 – Frames 7…10
(1)
Worst case condition including Vector Control board, HIM and Communication Module.
Voltage ND Hp/kW External Watts Internal Watts Total Watts Loss
240V 0.5 9 37 46
1 22 39 61
238 39 77
3 57 41 98
597 82 179
7.5 134 74 208
10 192 77 269
15 276 92 368
20 354 82 436
25 602 96 698
30 780 96 876
40 860 107 967
50 1132 138 1270
60 1296 200 1496
75 1716 277 1993
100 1837 418 2255
400V 0.37 11 42 53
0.75 19 44 63
1.5 31 45 76
2.2 46 46 93
478 87 164
5.5 115 79 194
7.5 134 84 218
11 226 99 326
15 303 91 394
18.5 339 102 441
22 357 103 459
30 492 117 610
37 568 148 717
45 722 207 930
55 821 286 1107
55 1130 397 1527
90 1402 443 1845
110 1711 493 2204
132 1930 583 2513
480V
0.5 11 42 53
119 44 63
2 31 45 76
346 46 93
5 78 87 164
7.5 115 79 194
10 134 84 218
15 226 99 326
20 303 91 394
25 339 102 441
30 357 103 459
40 492 117 610
50 568 148 717
60 722 207 930
75 821 286 1107
100 1130 397 1527
125 1402 443 1845
150 1711 493 2204
200 1930 583 2513
600V 0.5 9 37 46
1 14 40 54
225 40 65
3 41 42 83
559 83 142
7.5 83 75 157
10 109 77 186
15 177 93 270
20 260 83 343
25 291 95 385
30 324 95 419
40 459 109 569
50 569 141 710
60 630 195 825
75 1053 308 1361
100 1467 407 1874
125 1400 500 1900
150 1668 612 2280
Voltage ND Hp External Watts Internal Watts Total Watts Loss
480V 75 873 234 1107
100 1237 290 1527
125 1563 282 1845
150 1874 330 2204
200 2100 413 2513
600V
75 1091 270 1361
100 1537 337 1874
125 1584 316 1900
150 1895 385 2280
Voltage
Frame
Hp Rating Dissipation (Watts)
ND HD
AC Input DC Input
External Internal Total External Internal Total
400/480V 7 250 200 3422 514 3936 3098 497 3595
250 250 4224 618 4842 3848 599 4447
8 300 250 3125 569 3694 2698 547 3245
350 300 3588 681 4269 3091 655 3746
400 350 4284 850 5133 3692 816 4510
450 400 4850 1000 5850 4178 965 5143
500 450 5278 2010 7288 4506 1969 6475
9
600 500 8740 2270 11010 7752 2218 9970
10 700 600 8595 2339 10934 7470 2280 9750

Allen-Bradley powerflex 700 Specifications

General

Series	PowerFlex 700
Category	AC Drive
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Enclosure	Type 1
Control Method	Sensorless Vector
Communication	EtherNet/IP, ControlNet, DeviceNet, PROFIBUS DP, Modbus
