36 Rockwell Automation Publication 750-RM003A-EN-P - April 2018
Chapter 1 Selection Considerations
IP54, NEMA/UL Type 12
Dimensions (H x D), approx.
(width varies)
Dimensions exclude fan
housings, handles and so on.
—Rittal
2000 x 600 mm (78.7 x 23.6 in.)
See publication 750-TD101
and
publication 750-IN101
for detailed
dimensional data.
AC Input Cable Entry • (s), IP21 Rittal, bottom only
• (s), IP20 2500 MCC, top only
• (s) Bottom all frames
• (s) Top frames 8…9, specify power
option (-P17) w/o wiring bay
• (o) Top, frames 10…12, specify power
option (-P16) w/ wiring bay
DC Power Bus • Not applicable, IP21 Rittal,
connection terminals, near top/
front, side exit
• (s), IP20 2500 MCC, Centerline
horizontal bus bars, side exit,
frame 10 1250 A DC,
frame 13 3000 A DC
• (s) frames 8…10, 3000 A DC
• (s) frames 11…12, 4700 A DC
• (o) frames 8…10, 4700 A DC specify
power option code (-P46)
• Near top/back, horizontal bus bars, side
exit
Control Power Bus — • (s) 240V AC, 1 PH, 100 A rms
• (s) 24V DC, Auxiliary Control Bus,
100 ADC
• (s) 120/240V AC, 1 PH, User Control Bus,
100A rms
• Control Bus Connector taps are rated
10 A per pole.
Table 11 - Environmental Features
Description PowerFlex 700AFE Bus Supply PowerFlex 755TM Bus Supply
Cat No. 20Y… Cat. No. 20J…
Environmental Compliance Refer to Rockwell Automation website:
http://www.rockwellautomation.com/global/about-us/sustainability-ethics/
product-environmental-compliance.page?
Altitude (without derate) 1000 m (3000 ft)
See publication 20Y-UM001 for
detailed derating information.
1000 m (3000 ft)
See publication 750-TD100 for detailed
derating information.
Ambient Temperature Range
(without derate)
• 0…40
°C (32…104
°F)
• 0…35 °C (32…95 °F) Frame 13
600/690V AC
See publication 20Y-UM001 for
detailed derating information.
• -20…+40 °C (-4…+104
°F), all
frame ratings and enclosure types
See publication 750-TD100 for detailed
derating information.
Storage Temperature -40…+60 °C (-40…+140
°F) -40…+70
°C (-40…+158
°F)
Relative Humidity
(noncondensing)
5…95% 5…95%
Mechanical Shock Non-operational;
• 15G peak for 11 ms duration,
EN50178/EN60068-2-27
Operating; not applicable
Packed for shipment;
• Meets ATSM International standards
Operating (packaged products);
• 10G peak for 11 ms duration (+/-1 ms),
three shocks in each direction in each
axis. See the Shock Events information
in the Technical Data, publication 750-
TD100 for detailed information about
the maximum number of shock events.
Table 10 - Enclosure Features (Continued)
Description PowerFlex 700AFE Bus Supply PowerFlex 755TM Bus Supply
Cat No. 20Y… Cat. No. 20J…
