Rockwell Automation Publication 750-RM003A-EN-P - April 2018 87
Appendix A
Enclosure Information
Dimension and Enclosure
Types
Enclosure and dimensional information based on the compatible migration
solutions are shown in Table 16
through Table 23.
Figure 25 - Frame 10 PowerFlex 700AFE and Frame 8 PowerFlex 755TM Bus Supply Comparison
IMPORTANT The width dimension for parallel PowerFlex 700AFE assumes that each AFE
enclosure is secured directly to the adjacent unit. Since paralleling is not a
factory option, each installation is different. You must analyze your existing
parallel PowerFlex 700AFE arrangement before relying on these dimension
comparison tables.
640
(25)
1754.6
(69.1)
1204.1
(47)
1061.4
(42)
138.6
(5)
461.4
(18)
699.1
(28)
935
(36.8)
1090.25
(42.9)
1000
(39.4)
475
(18.7)
95.5
(3.8)
6.43
(0.3)
862.08
(33.9)
275
(10.8)
475
(18.7)
125
(4.9)
431
(17.0)
45
(1.8)
1006
(39.6)
400
(15.7)
1407
(55.4)
600
(23.6)
36
(1.4)
535
(21.1)
IP21, UL Type 1
2132
(83.9)
IP54, UL Type 12
2291
(90.2)
200
(7.9)
MCC IP20
Rittal IP21
Frame 8 PowerFlex 755TM Bus SupplyFrame 10 PowerFlex 700AFE
To Next Page
