Page #95 background imageLoading...
Page #95 background image
Rockwell Automation Publication 750-RM003A-EN-P - April 2018 95
Enclosure Information Appendix A
PowerFlex 755TM Bus Supply Installation Requirements
Environmental Conditions
Elevation above sea level without derating must be less than 1000 m
(3250 ft).
Ambient air temperature without derating must be between
-20…+40 °C (-4…+104 °F).
Relative humidity must be less than 95%, noncondensing.
The product must be installed indoors; there must be no dripping water
or other fluids in the room.
Cooling air must be clean without significant concentrations of sand,
corrosive or conductive dust (defined by IEC 721-1 as being less than
0.2 mg/m
3
of dust), or explosive gas.
Free from significant vibration.
Mounting Requirements
Install the product upright on a flat and level surface.
Verify that the product cabinet is square, vertical, and stable.
Verify that the filter and debris screens are installed.
Protect the cooling fan by avoiding dust or metallic particles.
Do not expose to a corrosive atmosphere.
Protect from moisture and direct sunlight.
The product must be anchored on a level floor. See outline dimension
drawings for the anchor point sizes and locations.
Table 43 - Environmental Specifications
Ambient temperature IP21, UL Type 1: -20…+40 °C (-4…+104 °F) frames 8…12, all ratings
IP54, UL Type 12: -20…+40 °C (-4…+104 °F) frames 8…12, all ratings
Ambient temperature of 50 °C (122 °F) or 55 °C (134 °F) with derating.
Storage temperature -40…+70 °C (-40…+158 °F)
Relative humidity 5…95% noncondensing
Atmospheric protection Harsh environment is defined as a copper or silver reactivity level greater than
1000 angstroms per 30 days exposure. No condensation allowed. Maximum allowable
humidity is 60% in the presence of corrosive gases. See ISA-71.04-2013 for details on
how to measure reactivity levels on copper and silver test coupons.
Table 44 - Airflow Requirements
Frame
755TL and 755TR Drives 755TM Bus Supplies 755TM Common Bus Inverters
CFM (ft
3
/min) CMS (m
3
/sec) CFM (ft
3
/min) CMS (m
3
/sec) CFM (ft
3
/min) CMS (m
3
/sec)
8 2375 1.12 1675 0.79 975 0.46
9 3775 1.78 2375 1.12 1675 0.79
10 6500 3.07 4400 2.08 2375 1.12
11 7900 3.73 5100 2.41 3075 1.45
12 10,000 4.72 6500 3.07 3775 1.78
