Chapter 1 Selection Considerations

Table 20 - 400V AC Dimensional Cross Reference

PowerFlex 700AFE Bus Supply (20Y…) PowerFlex 755TM Bus Supply (20J…)

Frame

Size x

Number

Units

(1)

Catalog Number

(1)

Enclosure

Type

Width

(2)

mm (in.)

Height

mm (in.)

Depth

mm (in.)

Frame

Size

Catalog Number

(3)

Width

(4)

mm (in.)

Height

IP21/IP54

mm (in.)

Depth

IP21/IP54

mm (in.)

F8 20J1FnC302… 1006 (39.6) 2132 (83.9)/

2291 (90.2)

676 (26.6)/

721 (38.4)

F8 20J1FnC367…

F8 20J1FnC460…

F10 x 1 20YD460… IP21 Rittal

IP20 MCC

1000 (39.4)

(5)

1204 (47)

2271 (89.4)

2380 (94)

671 (26.4)

958 (38)

F8 20J1FnC540…

F8 20J1FnC585…

F8 20J1FnC650…

F8 20J1FnC750…

F8 20J1FnC770…

F9 20J1FnC920… 1406 (55.4) 2132 (83.9)/

2291 (90.2)

676 (26.6)/

721 (38.4)

F10 x 2 2x 20YD460… IP21 Rittal

IP20 MCC

2000 (78.8)

2408 (94)

2271 (89.4)

2380 (94)

671 (26.4)

958 (38)

F9 20J1FnC1K0…

F9 20J1FnC1K1…

F9 20J1FnC1K2…

F13 x 1

F10 x 3

20YD1K3…

3x 20YD460A…

IP21 Rittal

IP20 MCC

IP21 Rittal

1800 (71)

2400 (95)

3000 (118.2)

2271 (89.4)

2380 (94)

2271 (89.4)

690 (27.2)

958 (38)

671 (26.4)

F9 20J1FnC1K4…

F13 x 1

F10 x 3

20YD1K3…

3x 20YD460A…

IP21 Rittal

IP20 MCC

IP21 Rittal

1800 (71)

(5)

2400 (95)

3000 (118.2)

2271 (89.4)

2380 (94)

2271 (89.4)

690 (27.2)

958 (38)

671 (26.4)

F10 20J1FnC1K6… 2406 (94.7) 2132 (83.9)

/2291 (90.2)

676 (26.6)

/721 (38.4)

F10 20J1FnC1K7…

F10 x 4 4x 20YD460A… IP21 Rittal 4000 (157.6) 2271 (89.4) 671 (26.4) F10 20J1FnC2K1…

F13 x 2

F10 x 5

F10 x 6

2x 20YD1K3…

5x 20YD460A…

6x 20YD460A…

IP21 Rittal

IP20 MCC

IP21 Rittal

3600 (142)

4800 (190)

5000 (197)

6000 (236.4)

2271 (89.4)

2380 (94)

2271 (89.4)

690 (27.2)

958 (38)

671 (26.4)

F11 20J1FnC2K8… 2606 (102.6)

(6)

2132 (83.9)/

2291 (90.2)

676 (26.6)/

721 (38.4)

F10 x 6 6x 20YD460A… IP21 Rittal 6000 (236.4) 2271 (89.4) 671 (26.4) F12 20J1FnC3K5… 3206 (126.2)

(6)

2132 (83.9)/

2291 (90.2)

676 (26.6)/

721 (38.4)

(1) Single and two in parallel available with IP21 Rittal (catalog code A) and IP20 2500 MCC (catalog code P or W) enclosures. More than 2 units in parallel only available with IP21 Rittal (catalog code A)

enclosures.

(2) The width dimension for parallel PowerFlex 700AFE assumes that each enclosure is secured directly to the adjacent unit. Since paralleling is not a factory option each installation will be different. It is

important that you analyze your existing parallel AFE arrangement before relying on these dimension comparison tables.

(3) <n> In catalog number is enclosure type; catalog code 3= IP21, catalog code 4= IP54.

(4) Optional wiring bays add to total width. If optional bays are required refer to technical data publication 750-TD100

, for dimensions and weights.

(5) The dimensions of these PowerFlex 700AFE units is less than the equivalent PowerFlex 755TM bus supply. Use judgment to ensure there is sufficient space for the migration solution.

(6) Assembled width, frames 11 and 12 are shipped as right and left side enclosures.
