Allen-Bradley PowerFlex 700AFE Migration Guide

70 Rockwell Automation Publication 750-RM003A-EN-P - April 2018
Chapter 2 Bus Supply Hardware and Parameter Conversion
P077 Current Lmt Val RW 13:100 Current Limit RW
P090 Param Access Lvl RW 0:30 Access Level RW
P095 Cnvrtr Status 1 RO 13:225 Line Side Sts 1 RO
P096 Cnvrtr Status 2 RO 14:1100 ACP0 Status RO
P097 Cnvrtr Alarm 1 RO 13:258 Alarm Status A RO
P098 Cnvrtr Alarm 2 RO 13:259 Alarm Status B RO
P100 Start Inhibits RO 13:235 L Start Inhibits RO
P124…P130 Fault 1…4 Codes RO 13:240 Fault Status A RO
13:241 Fault Status B RO
P154 Logic Mask RW 0:41 Logic Mask Cfg RW
0:42 Auto Mask RW
P156 Stop Owner RO 0:260 Stop Owner RO
P157 Start Owner RO 0:261 Start Owner RO
P158 Fault Clr Owner RO 0:264 Clear Flt Owner RO
(1) Default for PowerFlex 755TM Bus Supply is ‘Conv Logic’.
(2) Only used if 13:54 is set to ‘Manual’.
(3) Only used if 13:54 is set to ‘User Entered’.
Table 35 - Analog I/O Parameter Comparison
PowerFlex 700AFE Bus Supply PowerFlex 755TM Bus Supply
(1)
Parameter,
Bit
Display Name Read/
Write
Port:Parameter.Bit Display Name Read/
Write
P022 Analog In1 Value RO x:50 Anlg In0 Value RO
P201 Analog In 1 Hi RW x:51 Anlg In0 Hi RW
P202 Analog In 1 Lo RW x:52 Anlg In0 Lo RW
P203 Analog In 1 Loss RW x:53 Anlg In0 LssActn RW
P023 Analog In2 Value RO x:60 Anlg In1 Value RO
P204 Analog In 2 Hi RW x:61 Anlg In1 HI RW
P205 Analog In 2 Lo RW x:62 Anlg In1 Lo RW
P206 Analog In 2 Loss RW x:63 Anlg In1 LssActn RW
P207 Anlg Out Config RW x:70 Anlg Out Type RW
P208 Anlg Out Absolute RW x:71 Anlg Out Abs RW
P209 Analog Out1 Sel RW x:75 Anlg Out0 Sel RW
P210 Analog Out 1 Hi RW x:80 Anlg Out0 Hi RW
P211 Analog Out 1 Lo RW x:81 Anlg Out0 Lo RW
P212 Analog Out 2 Sel RW x:85 Anlg Out1 Sel RW
P213 Analog Out 2 Hi RW x:90 Anlg Out1 Hi RW
P214 Analog Out 2 Lo RW x:91 Anlg Out1 Lo RW
P215 Anlg Out1 Scale RW x:78…79 Anlg Out0 DataHi, Anlg
Out0 DataLo
RW
Table 34 - Parameter Comparison (Continued)
PowerFlex 700AFE Bus Supply PowerFlex 755TM Bus Supply
Parameter,
Bit
Display Name Read/
Write
Port:Parameter.Bit Display Name Read/
Write
