Rockwell Automation Publication 20D-TD002L-EN-P - July 2018 13
PowerFlex 700S Drives with Phase II Control
600…690V AC, Six-pulse, Three-phase Drives
Frame 9 & Up - IP21, NEMA/UL Type 1, (Position d = A)
380…480V AC, Six-pulse, Three-phase Drives
600V AC Input
(1)(2)
(1) Catalog number corresponds to output amps in this column (except for drive catalog numbers 20DF052 and 20DF062). Drive must be programmed to lower voltage to obtain higher currents that are shown at right.
(2) CE Certification testing has not been performed on 600V class drives Frames 1…4.
690V AC Input
(2)
IP20, NEMA/UL Type 1 Frame
Size
Output Amp Normal
Duty HP
Heavy-
Duty HP
Output Amp Normal
Duty kW
Heavy-
Duty kW
Cont. 1 Min. 3 Sec. Cont. 1 Min. 3 Sec. Cat. No., 20D…
1.7 2 2.6 1.0 0.75 20DE1P7A0EYNANANE 1
2.7 3.6 4.8 2.0 1.5 20DE2P7A0EYNANANE 1
3.9 4.3 5.9 3.0 2.0 20DE3P9A0EYNANANE 1
6.1 6.7 9.2 5.0 3.0 20DE6P1A0EYNANANE 1
9 9.9 13.5 7.5 5.0 20DE9P0A0EYNANANE 1
11 13.5 18 10 7.5 20DE011A0EYNANANE 1
17 18.7 25.5 15 10 20DE017A0EYNANANE 1
22 25.5 34 20 15 20DE022A0EYNANANE 2
27 33 44 25 20 20DE027A0EYNANANE 2
32 40.5 54 30 25 20DE032A0EYNANANE 3
41 48 64 40 30 20DE041A0EYNANANE 3
52 61.5 82 50 40 20DE052A0EYNANANE 3
62 78 104 60 50 20DE062A0EYNANANE 4
52 (46) 57 (69) 78 (92) 45 37.5 20DF052A0EYNANANE 5
60 (52) 66 (78) 90 (104) 55 45 20DF062A0EYNANANE 5
77 (63)
(3)
(3) These drives have dual current ratings; one for normal duty applications, and one for heavy-duty applications (in parentheses). The drive may be operated at either rating.
85 (94) 116 (126) 75 60 82 (60) 90 (90) 120 (123) 75 55 20DE077A0ENNANANE 5
99 (77)
(3)
109 (116) 126 (138) 100 75 98 (82)
(4)
(4) Rating is limited to 40 °C surrounding air.
108 (123) 127 (140) 90 75 20DE099A0ENNANANE 5
125 (99)
(3)
138 (149) 188 (198) 125 100 119 (98) 131 (147) 179 (196) 110 90 20DE125A0ENNANANE 6
144 (125)
(3)
158 (188) 216 (250) 150 125 142 (119) 156 (179) 213 (238) 132 110 20DE144A0ENNANANE 6
480V AC Input
(1)
(1) Catalog number corresponds to output amps in this column. Drive must be programmed to lower voltage to obtain higher currents that are shown at right.
380…400V AC Input IP21, NEMA/UL Type 1 Frame
Size
Output Amp Normal
Duty HP
Heavy-
Duty HP
Output Amp Normal
Duty kW
Heavy-
Duty kW
Cont. 1 Min. 3 Sec. Cont. 1 Min. 3 Sec. Cat. No., 20D…
261 (205)
(2)
287 (308) 410 (410) 200 150 261 (205) 287 (308) 410 (410) 132 110 20DD261A0ENNBNANE 9
300 (245)
(2)
330 (368) 450 (490) 250 200 300 (245) 330 (368) 450 (490) 160 130 20DD300A0ENNBNANE 9
385 (300)
(2)
424 (450) 600 (600) 300 250 385 (300) 424 (450) 600 (600) 200 160 20DD385A0ENNBNANE 10
460 (385)
(2)
506 (578) 770 (770) 350 300 460 (385) 506 (578) 770 (770) 250 200 20DD460A0ENNBNANE 10
500 (420)
(2)
550 (630) 750 (840) 450 350 500 (420) 550 (630) 750 (840) 250 250 20DD500A0ENNBNANE 10
590 (520)
(2)
649 (780) 956 (956) 500 450 590 (520) 649 (780) 956 (956) 315 250 20DD590A0ENNBNANE 11
650 (590)
(2)
715 (885) 1062 (1062) 500 500 650 (590) 715 (885) 1062 (1062) 355 315 20DD650A0ENNBNANE 11
730 (650)
(2)
803 (975) 1095 (1170) 600 500 730 (650) 803 (975) 1095 (1170) 400 355 20DD730A0ENNBNANE 11
820 (730)
(2)
902 (1095) 1230 (1314) 700 600 820 (730) 902 (1095) 1230 (1314) 450 400 20DD820A0ENNBNANE 12
920 (820)
(2)
1012 (1230) 1380 (1476) 800 700 920 (820) 1012 (1230) 1380 (1476) 500 450 20DD920A0ENNBNANE 12
1030 (920)
(2)(2)
(2) Rating is limited to 35 °C surrounding air.
1133 (1370) 1555 (1600) 900 800 1030 (920) 1133 (1370) 1555 (1600) 560 500 20DD1K0A0ENNBNANE 12
1150 (1030)
(2)
1265 (1545) 1620 (1620) 1000 900 1150 (1030) 1265 (1545) 1620 (1620) 630 560 20DD1K1A0ENNBNANE 13
1300 (1150)
(2)
1430 (1725) 2079 (2079) 1200 1000 1300 (1150) 1430 (1725) 2079 (2079) 710 630 20DD1K3A0ENNBNANE 13
1450 (1200)
(2)
1595 (1800) 2175 (2400) 1250 1000 1450 (1200) 1595 (1800) 2175 (2400) 800 710 20DD1K4A0ENNBNANE 13
