Page #12 background image
12 Rockwell Automation Publication 20D-TD002L-EN-P - July 2018
PowerFlex 700S Drives with Phase II Control
Product Selection
Frames 1…6 - IP20, NEMA/UL Type 1, (Position d = A)
208/240V AC, Six-pulse, Three-phase Drives
380…480V AC, Six-pulse, Three-phase Drives
240V AC Input
(1)
(1) Catalog number corresponds to output amps in this column. Drive must be programmed to lower voltage to obtain higher currents that are shown at right.
208V AC Input IP20, NEMA/UL Type 1 Frame
Size
Output Amp Normal
Duty HP
Heavy-
Duty HP
Output Amp Normal
Duty kW
Heavy-Duty
kW
Cont. 1 Min. 3 Sec. Cont. 1 Min. 3 Sec. Cat. No., 20D
4.2 4.8 6.4 1 0.75 4.8 5.6 7 0.75 0.55 20DB4P2A0EYNANANE 1
6.8 9 12 2 1.5 7.8 10.4 13.8 1.5 1.1 20DB6P8A0EYNANANE 1
9.6 10.6 14.4 3 2 11 12.1 17 2.2 1.5 20DB9P6A0EYNANANE 1
15.3 16.8 23 5 3 17.5 19.3 26.3 4.0 3.0 20DB015A0EYNANANE 1
22 24.2 33 7.5 5 25.3 27.8 38 5.5 4.0 20DB022A0EYNANANE 1
28 33 44 10 7.5 32.2 38 50.6 7.5 5.5 20DB028A0EYNANANE 2
42 46.2 63 15 10 48.3 53.1 72.5 11 7.5 20DB042A0EYNANANE 3
52 63 80 20 15 56 64 86 15 11 20DB052A0EYNANANE 3
70 78 105 25 20 78.2 86 117.3 18.5 15 20DB070A0ENNANANE 4
80 105 136 30 25 92 117.3 156.4 22 18.5 20DB080A0ENNANANE 4
104 (80)
(2)
(2) These drives have dual current ratings; one for normal duty applications, and one for heavy-duty applications (in parentheses). The drive may be operated at
either rating.
115 (120) 175 (160) 40 30 120 (92) 132 (138) 175 (175) 30 22 20DB104A0ENNANANE 5
130 (104)
(2)
143 (156) 175 (175) 50 40 130 (104) 143 (156) 175 (175) 37 30 20DB130A0ENNANANE 5
154 (130)
(2)
169 (195) 231 (260) 60 50 177 (150) 195 (225) 266 (300) 45 37 20DB154A0ENNANANE 6
192 (154)
(2)
211 (231) 288 (308) 75 60 221 (177) 243 (266) 308 (308) 55 45 20DB192A0ENNANANE 6
260 (205)
(2)
286 (305) 390 (410) 100 75 260 (205) 286 (305) 390 (410) 66 55 20DB260A0ENNANANE 6
480V AC Input
(1)
(1) Catalog number corresponds to output amps in this column. Drive must be programmed to lower voltage to obtain higher currents that are shown at right.
380…400V AC Input IP20, NEMA/UL Type 1 Frame
Size
Output Amp Normal
Duty HP
Heavy-
Duty HP
Output Amp Normal
Duty kW
Heavy-
Duty kW
Cont. 1 Min. 3 Sec. Cont. 1 Min. 3 Sec. Cat. No., 20D
2.1 2.4 3.2 1.0 0.75 2.1 2.4 3.2 0.75 0.55 20DD2P1A0EYNANANE 1
3.4 4.5 6 2.0 1.5 3.5 4.5 6 1.5 1.1 20DD3P4A0EYNANANE 1
5 5.5 7.5 3.0 2.0 5 5.5 7.5 2.2 1.5 20DD5P0A0EYNANANE 1
8 8.8 12 5.0 3.0 8.7 9.9 13.2 4.0 2.2 20DD8P0A0EYNANANE 1
11 12.1 16.5 7.5 5.0 11.5 13 17.4 5.5 4.0 20DD011A0EYNANANE 1
14 16.5 22 10 7.5 15.4 17.2 23.1 7.5 5.5 20DD014A0EYNANANE 1
22 24.2 33 15 10 22 24.2 33 11 7.5 20DD022A0EYNANANE 1
27 33 44 20 15 30 33 45 15 11 20DD027A0EYNANANE 2
34 40.5 54 25 20 37 45 60 18.5 15 20DD034A0EYNANANE 2
40 51 68 30 25 43 56 74 22 18.5 20DD040A0EYNANANE 3
52 60 80 40 30 56 64 86 30 22 20DD052A0EYNANANE 3
65 78 104 50 40 72 84 112 37 30 20DD065A0EYNANANE 3
77 (65)
(2)
(2) These drives have dual current ratings; one for normal duty applications, and one for heavy duty (in parentheses). The drive may be operated at either rating.
85 (98) 116 (130) 60 50 85 (72)
(3)
(3) 380…400V, 85 A rating is limited to 45 °C surrounding air.
94 (108) 128 (144) 45 37 20DD077A0ENNANANE 4
96 (77)
(2)
106 (116) 144 (154) 75 60 105 (85) 116 (128) 158 (170) 55 45 20DD096A0ENNANANE 5
125 (96)
(2)
138 (144) 163 (168) 100 75 125 (96) 138 (144) 163 (168) 55 45 20DD125A0ENNANANE 5
140 (105) 154 (158) 210 (210) 75 55 20DC140A0ENNANANE
(5)
(5) Catalog number corresponds to 380…400V AC input drive only.
5
156 (125)
(2)
172 (188) 233 (250) 125 100 170 (140) 187 (210) 255 (280) 90 75 20DD156A0ENNANANE 6
180 (156)
(2)
198 (234) 270 (312) 150 125 205 (170)
(4)
(4) 380…400V, 205 A rating is limited to 40 °C surrounding air.
220 (255) 289 (313) 110 90 20DD180A0ENNANANE 6
248 (180)
(2)
273 (270) 372 (360) 200 150 260 (205) 286 (308) 390 (410) 132 110 20DD248A0ENNANANE 6
