Allen-Bradley PowerFlex 700S User Manual

Rockwell Automation Publication 20D-TD002L-EN-P - July 2018 11
PowerFlex 700S Drives with Phase II Control
c1
c2
c3
c5
c4
PowerFlex 700S ND Rating
208/240V, 60 Hz Input
Code Amps Hp Frame
4P2 4.8 1.0
1
6P8 7.8 2.0
9P6 11 3.0
015 17.5 5.0
022 25.3 7.5
028 32.2 10 2
042 48.3 15
3
052 56 20
070 78.2 25
4
080 92 30
104 120 40
5
130 130 50
154 177 60
6
192 221 75
260 260 100
PowerFlex 700S ND Rating
400V, 50 Hz Input
Code Amps kW Frame
2P1 2.1 0.75
1
3P5 3.5 1.5
5P0 5.0 2.2
8P7 8.7 4.0
011 11.5 5.5
015 15.4 7.5
022 22 11
030 30 15
2
037 37 18.5
043 43 22
3
056 56 30
072 72 37
085 85 45 4
105 105 55
5
125 125 55
170 170 90
6
205 205 110
260 260 132
261 261 132
9
300 300 160
385 385 200
10
460 460 250
500 500 250
590 590 315
11
650 650 355
730 730 400
820 820 450
12
920 920 500
1K0 1030 560
1K1 1150 630
13
1K3 1300 710
1K4 1450 800
PowerFlex 700S ND Rating
480V, 60 Hz Input
Code Amps Hp Frame
2P1 2.1 1.0
1
3P4 3.4 2.0
5P0 5 3.0
8P0 8 5.0
011 11 7.5
014 14 10
022 22 15
027 27 20
2
034 34 25
040 40 30
3
052 52 40
065 65 50
077 77 60 4
096 96 75
5
125 125 100
156 156 125
6
180 180 150
248 248 200
261 261 200
9
300 300 250
385 385 300
10
460 460 350
500 500 450
590 590 500
11
650 650 500
730 730 600
820 820 700
12
920 920 800
1k0 1030 900
1K1 1150 1000
13
1K3 1300 1200
1K4 1450 1250
PowerFlex 700S ND Rating
690V, 50 Hz Input
(1)
(1) CE Certification testing has not been performed on 600V class drives
Frames 1…4.
Code Amps kW Frame
052 52 45
5
060 60 55
082 82 75
098 98 90
119 119 110
6
142 142 132
170 170 160
9
208 208 200
261 261 250
10
325 325 315
385 385 355
416 416 400
460 460 450
11
502 502 500
590 590 560
650 650 630
12
750 750 710
820 820 800
920 920 900
13
1K0 1030 1000
1K1 1180 1100
1K5 1500 1500 14
PowerFlex 700S ND Rating
600V, 60 Hz Input
(1)
(1) 600V class drives below 77 Amps (Frames 0-4) are declared
to meet the Low Voltage Directive. It is the responsibility of
the user to determine compliance to the EMC directive.
Code Amps Hp Frame
1P7 1.7 0
1
2P7 2.7 2
3P9 3.9 3
6P1 6.1 5
9P0 9 7.5
011 11 10
017 17 15
022 22 20
2
027 27 25
032 32 30
3
041 41 40
052 52 50
062 62 60 4
077 77 75
5
099 99 100
125 125 125 6
144 144 150
170 170 150
9
208 208 200
261 261 250
10
325 325 350
385 385 400
416 416 450
460 460 450
11
502 502 500
590 590 600
650 650 700
12
750 750 800
820 820 900
920 920 1000
13
1K0 1030 1100
1K1 1180 1300
1K5 1500 1600 14
