PowerFlex 700S Drives with Phase II Control
Catalog Number Explanation
1…3 4 5…7 8 9 10 11 12 13 14 15 16 17
20D
D
2P1 A 0 E Y N A N A N E
abcde ghif jklm
a
b
d
e
f
g
h
i
j
l
m
Drive
Code Type
20D PowerFlex 700S
Voltage Rating
Code Voltage Ph. Precharge
B
(1)
(1) For DC input on Frames 1…4, use the corresponding AC input code
B, C, D, or E.
240V AC 3 (6 pulse) -
C
(1)
400V AC 3 (6 pulse) -
D
(1)
480V AC 3 (6 pulse) -
E
(1)(2)
(2) 600V class drives below 77 Amps (Frames 0-4) are declared to meet
the Low Voltage Directive. It is the responsibility of the user to
determine compliance to the EMC directive.
600V AC 3 (6 pulse) -
F
(3)
(3) Frames 5 and greater.
690V AC 3 (6 pulse) -
H
(3)
540V DC - N
J
(3)
650V DC - N
K
(3)
810V DC - N
M
(3)
932V DC - N
N
(4)
(4) Frames 5 & 6 only.
325V DC - Y
P
(4)
540V DC - Y
R
(4)
650V DC - Y
T
(4)
810V DC - Y
W
(4)
932V DC - Y
Enclosure
Code Description
A
(1)
(1) IP20 for Frames 1…6, IP21 for Frames 9 and greater.
IP20, NEMA Type 1 with Conformal Coat
B
(2)
(2) Frames 10 and greater only.
IP20 NEMA Type 1, MCC, with Conformal Coat
H
(2)
IP54, NEMA Type 12, Rittal, with Conformal Coating
N
(3)
(3) Frames 9 and greater only.
Open/IP00, with Conformal Coat
HIM (Human Interface Machine)
Code Operator Interface
0 Blank Cover
3 Full Numeric LCD
C
(1)
(1) Frames 10 and greater only.
Full Numeric LCD, Door Mount
Documentation
Code Documents
E English Manual
N No Documentation
Brake
(1)
(1) Brake IGBT is standard on Frames 1…3 and optional on Frames
4…9 only.
Code w/Brake IGBT
YYes
NNo
Brake Resistor
Code w/Resistor
Y
(1)
(1) Not available for Frame 3 and greater.
Ye s
NNo
Emission
Code
CE Filter
(1)
(1) CE Certification testing has not been performed on 600V class drives
Frames 1…4.
CM Choke du/dt Filter
A
(2)
(2) Frames 1…6 only.
Yes Yes N o
B
(3)
(3) Frames 9 and greater only.
Yes No No
E
(4)
(4) Frame 14 only.
Yes No Yes
N
(5)
(5) For use on a high resistive ground, an ungrounded distribution
system, or a B phase grounded distribution system (Frame 9 only).
No No No
Comm Slot
Code Version
N None
C DPI ControlNet (Coax)
D DPI DeviceNet
E DPI EtherNet/IP
1
(1)
(1) Comm Slot options 1…6 are discontinued. They may exist
in older models.
k
DriveLogix ControlNet (Coax)
2
(1)
DriveLogix ControlNet Redundant (Coax)
3
(1)
DriveLogix ControlNet (Fiber)
4
(1)
DriveLogix ControlNet Redundant (Fiber)
5
(1)
DriveLogix DeviceNet (Open Conn.)
6
(1)
DriveLogix EtherNet/IP
Control Options
(1)
(1) Phase II control available only.
Code Logix Expansion Synchlink Cassette
A No No Expanded
B No Yes Expanded
C Yes No Expanded
D Yes Yes Expanded
G
(2)
(2) Frames 1…9 only.
N/A No Slim
H
(2)
N/A Yes Slim
Feedback
Code Option
N
(1)
(1) One encoder interface that is included with base drive.
Standard (Incremental Encoder)
A
(2)
(3)
(2) Expanded cassette is required.
(3) No longer available for sale as factory installed. They may
exist in older models..
Resolver
B
(2)(3)
Stegmann Hi-Resolution Encoder
C
(2)(3)
Multi-Device Interface
E
(2)
Second Encoder
S
(2)
Safe-Off (w/2nd Encoder)
T
(2)(3)
Stegmann Hi-Res Enc. (w/2nd Encoder)
U
(2)(3)
Stegmann Hi-Res Enc. (w/Safe-Off)
Additional Configuration
Code Description
E Phase II Control
K Phase II DriveLogix 5730
L
(1)
(2)
(1) This is an embedded EtherNet/IP option that is only
available with DriveLogix 5730.
(2) No longer available for sale as factory installed but can be
ordered as a user installed kit. (kit 20D-DL2-ENET0).
Phase II DriveLogix 5730 w/EtherNet/IP
To Next Page
