Page #15 background image
Rockwell Automation Publication 20D-TD002L-EN-P - July 2018 15
PowerFlex 700S Drives with Phase II Control
600…690V AC, Six-pulse, Three-phase Drives
IP20, NEMA/UL Type 1, DC Input Drives
Note: DC input for Frames 1…4 use the same code as AC input. Refer to the tables below for frames 5 and 6.
325V DC Input Drives
650V DC Input Drives
600…690V AC Input IP20, NEMA/UL Type 1 Frame
Size
Output Amp Normal
Duty HP
Heavy-Duty
HP
Cont.
(1)
(1) Catalog number corresponds to output amps in this column.
1 Min. 3 Sec. Cat. No., 20D
261 (208)
(2)
(2) These drives have dual current ratings; one for normal duty applications, and one for heavy-duty applications (in parentheses). The drive may be
operated at either rating.
287 (312) 375 (375) 250 200 20DE261B0ENNBNANE 10
325 (261)
(2)
358 (392) 470 (470) 350 250 20DE325B0ENNBNANE 10
385 (325)
(2)
424 (488) 585 (585) 400 350 20DE385B0ENNBNANE 10
416 (325)
(2)
458 (488) 585 (585) 450 350 20DE416B0ENNBNANE 10
460 (385)
(2)
506 (578) 693 (693) 450 400 20DE460B0ENNBNANE 11
502 (460)
(2)
552 (690) 828 (828) 500 450 20DE502B0ENNBNANE 11
590 (502)
(2)
649 (753) 904 (904) 600 500 20DE590B0ENNBNANE 11
650 (590)
(2)
715 (885) 1062 (1062) 700 650 20DE650B0ENNBNANE 12
750 (650)
(2)
825 (975) 1170 (1170) 800 700 20DE750B0ENNBNANE 12
820 (750)
(2)(3)(4)
(3) Rating is limited to 35 °C surrounding air.
(4) 600V class drives at 820 amps (ND) such as 20DF820 & 20DE820 are only capable of producing 95% of starting torque under 10 Hz.
902 (975) 1170 (1170) 900 700 20DE820B0ENNBNANE 12
325V DC Input
(1)
(1) Catalog number corresponds to output amps in this column. Drive must be programmed to lower voltage to obtain higher currents that are shown at right.
280V DC Input DC
Precharge
IP20, NEMA/UL Type 1 Frame
Size
Output Amp Normal
Duty HP
Heavy-
Duty HP
Output Amp Normal
Duty kW
Heavy-
Duty kW
Cont. 1 Min. 3 Sec. Cont. 1 Min. 3 Sec. Cat. No., 20D
104 (80)
(2)
(2) Frame 5 and 6 drives have dual current ratings; one for normal duty applications, and one for heavy-duty applications (in parentheses). The drive may be operated at either rating.
115 (120) 175 (160) 40 30 120 (92) 132 (138) 175 (175) 30 22 Y 20DN104A0ENNANANE 5
154 (130)
(2)
169 (195) 231 (260) 60 50 177 (150) 195 (225) 266 (300) 45 37 Y 20DN154A0ENNANANE 6
192 (154)
(2)
211 (231) 288 (308) 75 60 221 (177) 243 (266) 308 (308) 55 45 Y 20DN192A0ENNANANE 6
260 (205)
(2)
286 (305) 390 (410) 100 75 260 (205) 286 (305) 390 (410) 66 55 Y 20DN260A0ENNANANE 6
650V DC Input
(1)
(1) Catalog number corresponds to output amps in this column. Drive must be programmed to lower voltage to obtain higher currents that are shown at right.
540V DC Input DC
Precharge
IP20, NEMA/UL Type 1 Frame
Size
Output Amp Normal
Duty HP
Heavy-
Duty HP
Output Amp Normal
Duty kW
Heavy-
Duty kW
Cont. 1 Min. 3 Sec. Cont. 1 Min. 3 Sec. Cat. No., 20D
96 (77)
(2)
(2) Frame 5 and 6 drives have dual current ratings; one for normal duty applications, and one for heavy-duty applications (in parentheses). The drive may be operated at either rating.
106 (116) 144 (154) 75 60 105 (85) 116 (128) 158 (170) 55 45 N 20DJ096A0ENNANANE 5
96 (77)
(2)
106 (116) 144 (154) 75 60 105 (85) 116 (128) 158 (170) 55 45 Y 20DR096A0ENNANANE 5
125 (96)
(2)
138 (144) 163 (168) 100 75 125 (96) 138 (144) 163 (168) 55 45 N 20DJ125A0ENNANANE 5
125 (96)
(2)
138 (144) 163 (168) 100 75 125 (96) 138 (144) 163 (168) 55 45 Y 20DR125A0ENNANANE 5
156 (125)
(2)
172 (188) 233 (250) 125 100 170 (140) 187 (210) 255 (280) 90 75 N 20DJ156A0ENNANANE 6
156 (125)
(2)
172 (188) 233 (250) 125 100 170 (140) 187 (210) 255 (280) 90 75 Y 20DR156A0ENNANANE 6
180 (156)
(2)
198 (234) 270 (312) 150 125 205 (170)
(4)
(4) Rating is limited to 40 °C surrounding air.
220 (255) 289 (313) 110 90 N 20DJ180A0ENNANANE 6
180 (156)
(2)
198 (234) 270 (312) 150 125 205 (170)
(4)
220 (255) 289 (313) 110 90 Y 20DR180A0ENNANANE 6
248 (180)
(2)(3)
(3) Rating is limited to 45 °C surrounding air.
273 (270) 372 (360) 200 150 260 (205)
(3)
286 (308) 390 (410) 132 110 N 20DJ248A0ENNANANE 6
248 (180)
(2)(3)
273 (270) 372 (360) 200 150 260 (205)
(3)
286 (308) 390 (410) 132 110 Y 20DR248A0ENNANANE 6
