PowerFlex 700S Drives with Phase II Control
810V DC Input Drives
Factory Installed Options
Human Interface Modules IP20 - NEMA/UL Type 1 (Position e)
Documentation
Internal Brake IGBT
810 DC Input
(1)
(1) Catalog number corresponds to output amps in this column. Drive must be programmed to lower voltage to obtain higher currents that are shown at right.
932 DC Input DC
Precharge
IP20, NEMA/UL Type 1 Frame
Size
Output Amp Normal
Duty HP
Heavy-
Duty HP
Output Amp Normal
Duty kW
Heavy-
Duty kW
Cont. 1 Min. 3 Sec. Cont. 1 Min. 3 Sec. Cat. No., 20D…
99 (77)
(2)(3)
(2) Frame 5 and 6 drives have dual current ratings; one for normal duty applications, and one for heavy-duty applications (in parentheses). The drive may be operated at either rating.
(3) Rating is limited to 40 °C surrounding air.
109 (116) 126 (138) 100 75 98 (82)
(3)
108 (123) 127 (140) 90 75 Y 20DT099A0ENNANANE 5
144 (125)
(2)
158 (188) 216 (250) 150 125 142 (119) 156 (179) 213 (238) 132 110 Y 20DT144A0ENNANANE 6
Description Cat. Code
(Position f)
English Manual
E
No Manual
N
Drive Input Voltage Brake IGBT Frame Cat. Code
(Position g)
208…480V AC Standard
1…3 Y
Optional
4N
(1)
(1) By default, frames 4…9 are not equipped with a brake IGBT. A brake IGBT can be added by choosing Y (yes)
in position ‘g’ of the catalog string.
5N
(1)
6N
(1)
9N
(1)
Esc
7 8 9
4 5 6
1 2 3
.
0 +/-
Sel
Jog
Alt
Exp
Param #
S.M.A.R.T.
Exit
Lang
Auto / Man
Remove
Cat. Code: 0
No HIM (Blank Plate)
Cat. Code: 3
LCD Display, Full Numeric Keypad
Cat. Code: C
Door Mounted Bezel LCD Display, Full
Numeric Keypad Frame 10 & Up
