Allen-Bradley PowerFlex 700S User Manual

Rockwell Automation Publication 20D-TD002L-EN-P - July 2018 17
PowerFlex 700S Drives with Phase II Control
Internal Dynamic Brake Resistors
These resistors have a limited duty cycle. See the PowerFlex Dynamic Braking Resistor Calculator guide, publication
PFLEX-AT001, to determine if an internal resistor will be sufficient for your application. An external resistor may be
required.
Internal EMC Filter
Internal Communication Adapters
Control Options
Feedback Options
Drive Input Voltage Frame Brake Resistance Cat. Code
W (Position h)
208…240V AC Frame 1 (1.0…5.0 HP)
62 Y
1 (7.5 Hp)
22 Y
2
22 Y
380…600V AC 1
115 Y
2
68 Y
All
–N
Drive Input Voltage
Frame CE Filter Cat. Code
(Position i)
208…240V AC
1…6 with Filter A
380…480V AC
1…6 with Filter A
380…500V AC
9 No Filter
(1)
(1) For use on a high resistive ground or ungrounded distribution system.
N
380…500V AC
9 & Up with Filter B
600…690V AC
1…6 with Filter A
Description
Cat. Code
(Position j)
None
N
ControlNet™ Communication Adapter (Coax)
C
DeviceNet™ Communication Adapter
D
EtherNet/IP™ Communication Adapter
E
Control
Option
Description Cat. Code
(Position k)
Phase II
Control
Expanded Cassette Only
A
Expanded Cassette w/SynchLink
B
Expanded Cassette w/Logix Expansion Board
C
Expanded Cassette w/Logix Expansion Board and SynchLink
D
Slim Cassette
G
(1)
(1) Only available for frames 1…9
Slim Cassette w/SynchLink
H
(1)
Description Cat. Code
(Position l)
No Option (includes Standard Encoder Interface)
N
Second Encoder, 5V or 12V Configurable by the Drive
(1)
E
DriveGuard Safe-Off (w/2nd Encoder)
(1)
(1) Requires Expanded Cassette.
S
