30 ProcessLogix and ControlLogix System Redundancy Module
Publication
1757-IN092E-EN-P - November 2007
If you encounter one of these error codes, write the Exxx code down and
contact Rockwell Automation Product Support by using one of the methods
described on the back cover.
Recovery Messages
For certain faults, the module status display will provide recovery instructions.
Up to four, four-character words will be displayed.
Specifications
System Redundancy Module, Series B - 1757-SRM
Recovery
Instruction Code
Description
RPLC MOD Replace the module.
RSET MOD Reset the module.
REMV MOD Remove the module.
SEAT MOD Reinsert the module into the chassis.
Attribute Value
Backplane current 0.75 A @ 3.3V dc
1.0 A @ 5.1V dc
0.160 A @ 24V dc
Dimensions
(HxWxD), approx.
Standard ControlLogix chassis 2 slots wide
14.5 x 7 x 14 cm (5.71 x 2.76 x 5.51 in.)
Weight, approx. 0.452 kg (14.53 oz)
Mounting ControlLogix chassis
Enclosure type rating None (open-style)
IEC temperature code T4
North American
temperature code
T4A
