Allen-Bradley ProcessLogix B Series User Manual

32 ProcessLogix and ControlLogix System Redundancy Module
Publication
1757-IN092E-EN-P - November 2007
Environmental Specifications
Attribute Value
Temperature,
operating
0
… 60 °C (32 … 140 °F)
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
Temperature, storage –40
… 85 °C (–40 … 185 °F)
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
Relative humidity 5
… 95% noncondensing
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat)
Vibration IEC 60068-2-6 (Test Fc, Operating): 2 g @ 10
… 500 Hz
Shock, nonoperating IEC 60068-2-27 (Test Ea, Unpackaged Shock):
50 g
Shock, operating IEC 60068-2-27 (Test Ea, Unpackaged Shock):
30 g
Emissions CISPR 11: Group 1, Class A
ESD immunity IEC 61000-4-2:
6 kV contact discharges
8 kV air discharges
EFT/B immunity IEC 61000-4-4:
±4 kV at 5 kHz on signal ports
Radiated RF immunity IEC 61000-4-3:
10V/m with 1 kHz sine-wave 80%AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100%AM at 900 MHz
10V/m with 200 Hz 50% Pulse 100%AM at 1890 MHz
3V/m with 1 kHz sine-wave 80%AM from 2000…2700 MHz
Conducted RF
immunity
IEC 61000-4-6:
10V rms with 1 kHz sine-wave 80%AM from 150 kHz…80 MHz
Surge transient
immunity
IEC 61000-4-5:
±2 kV line-earth (CM) on shielded ports
