Allen-Bradley PV550 User Manual

Publication 2711-UM014B-EN-P
A-12 Specifications
PanelView 1000 Color &
Grayscale
Electrical
AC Power - PV1000G and PV1000C
Supply Voltage Limits
Power Consumption
85 to 264V ac, 47 to 63 Hz
100 VA maximum
DC Power - PV1000G
Supply Voltage Limits
Power Consumption
DC Power - PV1000C
Supply Voltage Limits
Power Consumption
18 to 32 V dc (24V dc nominal)
40 Watts max. (1.7A @ 24V dc)
18 to 32 V dc (24V dc nominal)
50 Watts max. (2.1A @ 24V dc)
Mechanical
Enclosure NEMA Type 12/13, 4X (Indoor use only) IP54,
IP65
LED Indicators
COMM
Fault
Green
Red
Weight - PV1000G
Keypad
Touch
3.27 kg (7.2 lbs)
3.18 kg (7.0 lbs)
Weight - PV1000C
Keypad
Touch Screen
3.72 kg (8.2 lbs)
3.58 kg (7.9 lbs)
Dimensions-PV1000G/1000C Keypad
mm
inches
282 (H) x 423 (W) x 112 (D)
11.11 (H) x 16.64 (W) x 4.40 (D)
Dimensions - PV1000G/1000C Touch Screen
mm
inches
282 (H) x 370 (W) x 112 (D)
11.11 (H) x 14.58 (W) x 4.40 (D)
Installed Depth - PV1000G 97 mm (3.81 inches)
129 mm (5.06 inches) with memory card retainer
220 mm (8.65 inches) with memory card retainer
and clearance to insert and remove memory card
Installed Depth - PV1000C 99 mm (3.89 inches)
131 mm (5.14 inches) with memory card retainer
222 mm (8.73 inches) with memory card retainer
and clearance to insert and remove memory card
Terminal Memory
Total Application Flash Memory 1008K bytes (application screens)
