Specifications A-11
Character Sizes PV900M (Pixel size = 0.33 x 0.33 mm)
Character Sizes PV900C (Pixel size = 0.27 x 0.27 mm)
Size in Pixels
width x height)
Characters/Row Maximum Rows Dimensions in mm
Width x Height
8 x 16 79 24 2.6 x 5.3
8 x 24 79 16 2.6 x 7.9
16 x 24 39 16 5.3 x 7.9
24 x 32 26 12 7.9 x 10.6
32x 40 19 9 10.6 x 13.2
Size in Pixels
width x height)
Characters/Row Maximum Rows Dimensions in mm
Width x Height
8 x 16 79 24 2.2 x 4.3
8 x 24 79 19 2.2 x 6.5
16 x 24 39 19 4.3 x 6.5
24 x 32 26 14 6.5 x 8.6
32x 40 19 11 8.6 x 10.8
